Model 2290
-5 5 kV Power Supply User's Manual Section 5:
Status messages
2290-5-900-01 Rev. A/December 2013 5-3
Table: Standard event status register
Bit Decimal value Name Description
0
1
Unused
1
2
Unused
2
4
Query Error
Set by an output queue overflow.
3 8 Recall Error Set if a stored configuration setting is corrupt.
4 16 Execution
Set by an out-of-range parameter, or non-completion of a command due to a
condition such as an overload.
5 32
Command
Error
Set by a command syntax error or unrecognized command.
6
64
URQ
Set by any button press.
7
128
PON
Set by power-on.
Note: Set ESB bit in Status Byte Register by sending *ESE command with desired condition. For example, *ESE 16 sets ESB
on execution error.
