Section
8: Performance verification Model 2290-5 5 kV Power Supply
User's Manual
8-4 2290-5-900-01 Rev. A/December 2013
Table: Filters off DC voltage accuracy
Output volts Volts display limits Multimeter voltage reading limits
500
495
505
0.4975
0.5026
1000 995 1005 0.9974 1.0026
1500 1495 1505 1.4974 1.5027
2000 1995 2005 1.9973 2.0027
2500 2495 2505 2.4973 2.5028
3000
2995
3005
2.9972
3.0028
3500
3495
3505
3.4972
3.5029
4000
3995
4005
3.9971
4.0029
4500
4495
4505
4.4971
4.5030
5000
4995
5005
4.9970
5.0030
Table: Filter 1 enabled DC voltage accuracy
Output volts Volts display limits Multimeter voltage reading limits
500 493 507 0.4950 0.5051
1000
993
1007
0.9949
1.0051
1500
1493
1507
1.4949
1.5052
2000
1993
2007
1.9948
2.0052
2500
2493
2507
2.4948
2.5053
3000
2993
3007
2.9947
3.0053
