Keithley DMM6500 Quick Start Guide

FAQs and next steps
Next steps
Additional information
This manual has prepared you to start using your new
DMM6500 Multimeter for your application. For more
detailed information, refer to the Keithley Instruments Model
DMM6500 Reference Manual.
Also see tek.com/keithley for support and additional
information about the instrument. From the website, you
can access:
• The Low Level Measurements Handbook: Precision DC
Current, Voltage, and Resistance Measurements
• Switching Handbook: A Guide to Signal Switching in
Automated Test Systems
• Application notes
• Updated drivers
• Information about related products
Your local Field Applications Engineer can help you with
product selection, conguration, and usage. Check the
website for contact information.

Keithley DMM6500 Specifications

General

Resolution	6.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
AC Current Range	10 µA to 10 A
Temperature Range	-200 °C to 1820 °C
Display	5-inch capacitive touch screen
Resistance Range	100 MΩ
Frequency Range	3 Hz
Sampling Rate	1 MS/s
Connectivity	USB, LAN, GPIB (optional), TSP-Link
Memory	7 million readings
