FAQs
How do I save data to a USB fl ash drive?
1. Insert a USB fl ash drive into the front-panel USB
connector.
2. Press the MENU key.
3. Under Measure, select Reading Buffers.
4. Select defbuffer1.
5. Select Save To USB.
6. Enter the fi le name.
7. Select Enter (on the screen).
8. A confi rmation message is displayed. Select Yes.
The data is saved to a .csv fi le.
My data looks odd or is wrong. What should I do?
Verify the connections from the instrument to the test fi xture.
Also check the connections from the DUT to the test fi xture
socket.
How do I change the command set?
In addition to the front panel options, you can use a remote
interface to set up the instrument. You can choose one of the
following command sets:
• SCPI: An instrument-specifi c language built on the SCPI
standard.
• TSP: A programming language that can be used to send
individual commands or combine commands into scripts.
You cannot combine the command sets.
As delivered from Keithley Instruments, the Model DMM7510 is
set to work with the SCPI command set.
To set the command set using the front panel:
1. Press the MENU key.
2. Under System, select Settings.
3. Select the button next to Command Set.
4. Select the command set.
5. You are prompted to reboot the instrument.
