To set register bits:
status.operation.user.** = status.operation.user.BIT0
status.operation.user.** = status.operation.user.BIT1
status.operation.user.** = status.operation.user.BIT2
status.operation.user.** = status.operation.user.BIT3
status.operation.user.** = status.operation.user.BIT4
status.operation.user.** = status.operation.user.BIT5
status.operation.user.** = status.operation.user.BIT6
status.operation.user.** = status.operation.user.BIT7
status.operation.user.** = status.operation.user.BIT8
status.operation.user.** = status.operation.user.BIT9
status.operation.user.** = status.operation.user.BIT10
status.operation.user.** = status.operation.user.BIT11
status.operation.user.** = status.operation.user.BIT12
status.operation.user.** = status.operation.user.BIT13
status.operation.user.** = status.operation.user.BIT14
To read registers:
print(status.operation.user.*)
print(status.operation.user.condition)
print(status.operation.user.enable)
B0
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
Table D-7 (cont.)
Operation event commands
Command
1
Bit
1. * = '.ntr', '.ptr' and '.enable'; smuX = smua or smub.
** = '.ntr', '.ptr', '.enable', and ‘.condition’; smuX = smua or smub.
