Section 1
Front Panel Operation
In this section:
Topic
Page
Safety symbols and terms 1-2
Front and rear panel familiarization 1-2
Front panel overview 1-2
Rear panel overview 1-6
What are the source-measure capabilities? 1-8
Models 2601 and 2602 1-8
Models 2611 and 2612 1-8
How do I power-up the instrument? 1-8
Connect to line power 1-9
Turn on power 1-9
Set line frequency 1-9
How do I make measurements? 1-10
Connect the DUT 1-10
Select source and set source level 1-10
Set compliance limit 1-11
Select measurement function and range 1-11
Turn output on 1-11
Make measurements 1-11
Turn output off 1-12
How do I use the buffer? 1-15
Connect the DUT 1-15
