3-10 Test Script Processor Interaction Series 2600 System SourceMeters User’s Manual
2600S-900-01 Rev. A / May 2006 Return to In this section:
Figure 3-4
Run configuration example - Main tab shown
2. In the Configurations area of the Run box, select the KIGeneral script. The
launch configuration tabs for that script will appear in the Run box.
3. Presently, the Name of the script is KIGeneral. You should change the name
so the script is not confused with the factory script of the same name that
resides in the Series 2600. Change the script Name to KIGeneralUser and
click the Apply button.
NOTE Figure 3-4 and 7. show how the Run box will look after the
launch is configured.
Changing the script Name from KIGeneral to KIGeneralUser
also changes the name in the Configurations area.
