Kelly KLS-S Cheetah series Sinusoidal Permanent Motor Controller User’s Manual V1.13
5
2.3 Specifications
•Frequency of Operation: 10KHz or 20KHz.
•Standby Battery Current: < 0.5mA.
•5V or 12V Sensor Supply Current: 40mA.
•Controller supply voltage range: PWR, 18V to 86V for controllers rated equal or lower than
72V.
•Supply Current, PWR, 30mA Typical.
•Configurable battery voltage range, B+.
•Standard Throttle Input: 0-5 Volts(3-wire resistive pot), 1-4 Volts(hall active throttle).
•Throttle Input: 0-5 Volts. Can use 3-wire pot to produce 0-5V signal.
•Full Power Operating Temperature Range: 0℃ to 70℃(MOSFET temperature).
•Operating Temperature Range: -40℃to 100℃ (MOSFET temperature).
•Max Battery Current :Configurable.
2.4 Name Regulation
The name regulation of Kelly BLDC motor controllers:
KLS7230S
KLS: Kelly BLDC motor controller based on sinusoidal waveform which is supposed to
work with BLDC motor with three hall sensors.
72: 72V batteries
S: Mini case for the controller
Kelly KLS-S Space-saving Sinusoidal Brushless Motor Controller
Model
1 Minute Boost
Current(Amp)
Continuous
Current(Amp)
Nominal
Voltage(Volt)
Max Operating
Voltage(Volt)
KLS4812S
120
50
36-48
30-60
KLS4818S
200
80
36-48
30-60
KLS4830S
300
120
36-48
30-60
KLS7212S
120
50
48-72
40-86
KLS7218S
200
80
48-72
40-86
KLS7230S
300
120
48-72
40-86
