KEMPOWELD 3200W
7.3.2000/V216302 3145150/1921850
Order no. Part Description Pc.
4279480 A001 CONTROL CARD
A
001 KWELD3200-4000
W
1
4279500 A002 CONTROL CARD A002 KWELD 4000W 1
9755223 C001 CAPACITOR 8UF/450V AC 1
9772551 F001 FUSE BOX + NUT 1
9772551 F002 FUSE BOX + NUT 1
4287570 G001 RECTIFICATION UNIT KWELD3200/4000/4000
W
1
4287420 G002 PARALLEL DIODE KEMPOWELD 1
9775729 H001 SIGNAL LAMP YELLOW 1
9775731 H003 SIGNAL LAMP RED 1
9775729 H004 SIGNAL LAMP YELLOW 1
9764130 K001 CONTACTOR 1
3138510 L001 CHOKE KWELD,KMAT 3200 1
9544214 M001 COOLING FAN MASTER 2800/3500 1
3138320 M002 PUMP-MOTOR COMB. SIMACO 1
9540410 M002 PUMP-MOTOR 0
4287840 R001 RESISTOR 0.23 OHM KWELD 1
4266150 R002 SHUNT RESISTOR 300A/60MV 1
9753587 R004 PTC RESISTOR +60 C 1
9761225 S001 FLIP-FLOP SWITCH WITH PILOT LAMP 1
976052101 S002 SWITCH D22,5 2
9761221 S004 FLIP-FLOP SWITCH WITH PILOT LAMP 1
9761622 S005 PRESSURE SWITCH 1
2066190 T001 TRANSFORMER KWELD,KMAT 3200 1
3141290 T002 AUXIL. TRANSFORMER 1
9771530 X003 MACHINE SOCKET DIX BE 50/70 2
4191441 ZG001 RC PROTECTION 1
2066280 010 UNDERCARRIAGE KWELD,KMAT3200/400
0
1
9547105 030 WHEEL 2
9547771 040 WHEEL T-50 LHPL 200 PK 2
2061410 050 REAR GRATE MASTER 2800/3500 1
2069250 055 INSUL. F COOLING FAN 1
3001873 060 CLAMP D30 1
3001875 070 INSULAT. PLATE FOR CLAMP 1
3138950 100 AXLE INSULATION 1
4279940 110 FLAT CABLE L=380 1
2062900 145 PLASTIC HANDLE 26X50X217/188 1
3144940 140 SIDE PLATE LEFT KWELD 3200W,4000W 1
3144950 150 SIDE PLATE RIGHT KWELD 3200W,4000W 1
1028360 160 COVER PLATE KWELD 3200W,4000W 1
1028370 170 FRONT PLATE KEMPOWELD 3200W 1
1028350 180 REAR PLATE KWELD 3200W,4000W 1
9592126 190 WATER TANK 1
9370162 200 PA-HOSE BLUE 8/6 0,52
9373216 210 RUBBER HOSE 13 MM 0,7
4278740 220 WATER HOSE KW 4000W 1
9373215 230 RUBBER HOSE 10/17 MM 0,3
4279930 240 HOSE CONNECTOR R1/8 - 9.5 KL 1
4279920 250 HOSE CONNECTOR R1/8 - 6 ML 1
9568956 260 IN-LINE CONNECTOR 1
9568957 270 BRANCH CONNECTOR 2060-1/4 1
9761302 290 PROTECTION SWITCHES'LEVER 2
9885031 300 STICKER, GREEN 1
9885032 310 STICKER, RED 1
3142290 320 CIRCUIT DIAGRAM KEMPOWELD 3200W 1
