Kemppi 3200 Technical & Service Manual

KEMPOWELD 4000/4000W
7.3.2000/V215304 3145140/1921840
Order no. Part Description Pc.
4279480 A001 CONTROL CARD A001 KWELD3200-4000W 1
9772551 F001 FUSE BOX + NUT 1
4287570 G001 RECTIFICATION UNIT KWELD3200/4000/4000W 1
4287420 G002 PARALLEL DIODE KEMPOWELD 1
9775729 H001 SIGNAL LAMP YELLOW 1
9775730 H002 SIGNAL LAMP GREEN 1
3138540 L001 CHOKE KWELD,KMAT 4000 1
9544214 M001 COOLING FAN MASTER 2800/3500 1
4287840 R001 RESISTOR 0.23 OHM KWELD 1
4266150 R002 SHUNT RESISTOR 300A/60MV 1
9771530 X003 MACHINE SOCKET DIX BE 50/70 1
4191441 ZG001 RC PROTECTION 1
2070060 0-010 UNDERCARRIAGE KEMPOMAT, KEMPOWELD 1
9547105 0-030 WHEEL 2
9547770 0-040 WHEEL, ROTATING 2
2061410 0-050 REAR GRATE MASTER 2800/3500 1
3001873 0-060 CLAMP D30 1
3001875 0-070 INSULAT. PLATE FOR CLAMP 1
3138950 0-100 AXLE INSULATION 1
4279940 0-110 FLAT CABLE L=380 1
2062900 0-145 PLASTIC HANDLE 26X50X217/188 1
***KEMPOWELD 4000W 230V******
9764160 1K001 CONTACTOR 1
9760615 1S001 SWITCH 32A O-Y- D K60/10 D22.5 1
9760616 1S002 SWITCH 32A 2
2066180 1T001 TRANSFORMER 230V K-WELD 4000 1
***KEMPOWELD 4000W 400V******
9764130 2K001 CONTACTOR 1
976051501 2S001 Y/D-SWITCH 1
976052101 2S002 SWITCH D22,5 2
2066170 2T001 TRANSFORMER 400V K-WELD 4000 1
***KEMPOWELD 4000 230V******
9764160 3K001 CONTACTOR 1
9760615 3S001 SWITCH 32A O-Y- D K60/10 D22.5 1
9760616 3S002 SWITCH 32A 2
2066180 3T001 TRANSFORMER 230V K-WELD 4000 1
***KEMPOWELD 4000 400V******
9764130 4K001 CONTACTOR 1
976051501 4S001 Y/D-SWITCH 1
976052101 4S002 SWITCH D22,5 2
2066170 4T001 TRANSFORMER 400V K-WELD 4000 1
***KEMPOWELD 4000W 230/400V***
3144940 5-140 SIDE PLATE LEFT KWELD 3200W,4000W 1
3144950 5-150 SIDE PLATE RIGHT KWELD 3200W,4000W 1
1028360 5-160 COVER PLATE KWELD 3200W,4000W 1
1028340 5-170 FRONT PLATE KEMPOWELD 4000W 1
1028350 5-180 REAR PLATE KWELD 3200W,4000W 1
9592126 5-190 WATER TANK 1
9370162 5-200 PA-HOSE BLUE 8/6 0,52
9373216 5-210 RUBBER HOSE 13 MM 0,7
4278740 5-220 WATER HOSE KW 4000W 1
9373215 5-230 RUBBER HOSE 10/17 MM 0,3
4279930 5-240 HOSE CONNECTOR R1/8 - 9.5 KL 1
4279920 5-250 HOSE CONNECTOR R1/8 - 6 ML 1
9568956 5-260 IN-LINE CONNECTOR 1
9568957 5-270 BRANCH CONNECTOR 2060-1/4 1
9581007 5-280 HEAT EXCHANGER 140X179 SIMACO 1
9761302 5-290 PROTECTION SWITCHES'LEVER 2
9885031 5-300 STICKER, GREEN 1
9885032 5-310 STICKER, RED 1

Kemppi 3200 Specifications

General

Brand	Kemppi
Model	3200
Category	Welding System
Language	English
