KEMPOWELD 4000/4000W

7.3.2000/V215304 3145140/1921840

Order no. Part Description Pc.

3139060 5-320 CIRCUIT DIAGRAM KEMPOWELD 4000W 1

4279500 5A002 CONTROL CARD A002 KWELD 4000W 1

9755223 5C001 CAPACITOR 8UF/450V AC 1

9772551 5F002 FUSE BOX + NUT 1

9775731 5H003 SIGNAL LAMP RED 1

9775729 5H004 SIGNAL LAMP YELLOW 1

3138320 5M002 PUMP-MOTOR COMB. SIMACO 1

9540410 5M002 PUMP-MOTOR 0

9753587 5R004 PTC RESISTOR +60 C 1

9761221 5S004 FLIP-FLOP SWITCH WITH PILOT LAMP 1

9761622 5S005 PRESSURE SWITCH 1

3141300 5T002 AUXIL. TRANSFORMER 1

***KEMPOWELD 4000 230/400V***

2070800 6-140 SIDE PLATE LEFT KEMPOWELD 3200, 4000 1

2070810 6-150 SIDE PLATE RIGHT KEMPOWELD 3200, 4000 1

1028120 6-160 COVER PLATE KEMPOWELD 1

2070780 6-170 FRONT PLATE KEMPOWELD 4000 1

2070790 6-180 REAR PLATE KEMPOWELD 3200/4000 1

3139050 6-190 CIRCUIT DIAGRAM KEMPOWELD 4000 1

3141290 6T002 AUXIL. TRANSFORMER 1
