KEMPOWELD 5500W
6.08.2001/V216501 2068970/1921690
Order no. Part Description Pc.
4279480
A
001
CONTROL CARD A001 KWELD3200-4000W 1
4279500
A
002
CONTROL CARD A002 KWELD 4000W 1
4287250
A
003
PTC PROTECTION CARD K-WELD 5500W 1
9755223
C002
CAPACITOR 8UF/450V AC 1
9755177
C001
CAPACITOR 4UF/400VAC 1
9772551
F001
FUSE BOX + NUT 1
9772551
F002
FUSE BOX + NUT 1
9750175
G001
RECTIFICATION UNIT 1
4287420
G002
PARALLEL DIODE KEMPOWELD 1
9775729
H001
SIGNAL LAMP YELLOW 1
9775730
H002
SIGNAL LAMP GREEN 1
9775731
H003
SIGNAL LAMP RED 1
9775729
H004
SIGNAL LAMP YELLOW 1
9764160
K001
CONTACTOR 1
3142030
L001
CHOKE K-WELD 5500W 1
9544262
M001
COOLING FAN 1
9540410
M002
PUMP-MOTOR 1
3138320
M002
PUMP-MOTOR COMB. SIMACO 1
4286970
R001
RESISTOR 0.23 OHM KWELD5500W 1
4286540
R002
SHUNT RESISTOR 300A/60MV KWELD5500W 1
4282710
R004
PTC RESISTOR 1
9760615
S001
SWITCH 32A O-Y- D K60/10 D22.5 1
9760616
S002
SWITCH 32A 2
9761221
S004
FLIP-FLOP SWITCH WITH PILOT LAMP 1
9761622
S005
PRESSURE SWITCH 1
2068950
T001
TRANSFORMER KWELD 5500W 1
3141300
T002
AUXIL. TRANSFORMER 1
9771540
X003
MACHINE SOCKET 70 MM2 3
6185666
005
VOLT/AMP. METER. UNI MSD 1 1
1027740
010
SIDE PLATE RIGHT KWELD 5500W 1
1027750
020
SIDE PLATE LEFT KWELD 5500W 1
1027710
030
COVER PLATE KEMPOWELD 5500W 1
1027730
040
FRONT PLATE KEMPOWELD 5500W 1
1027770
050
REAR PLATE KEMPOWELD 5500W 1
3001873
060
CLAMP D30 1
3001875
070
INSULAT. PLATE FOR CLAMP 1
9592158
080
COOLING FAN HOLDER 1
4281090
090
HANDLE PIPE KMIG 4000, 3200 1
9592126
100
WATER TANK 1
9547150
110
WHEEL 2
9547711
120
WHEEL, ROTATING 2
1027050
130
LEFT PULL-HANDLE 1
1026960
140
RIGHT PULL-HANDLE 1
3138950
150
AXLE INSULATION 1
9373215
160
RUBBER HOSE 10/17 MM 0,92
9568903
170
FEMALE FAST CONNECTION 1/8 2
4286530
180
WATER HOSE 2
4279930
190
HOSE CONNECTOR R1/8 - 9.5 KL 1
9540415
195
REPAIR SET FOR PUMP SIMACO 1
9551058
200
L CONNECTION 2020-R1/4-R1/4 1
9568956
210
IN-LINE CONNECTOR 1
9568938
220
HOSE CONNECTOR R1/4-12 2
9568957
240
BRANCH CONNECTOR 2060-1/4 1
9581006
260
HEAT EXCHANGER 1
4280650
270
SWITCH PROTECTION 1
3142130 CIRCUIT DIAGRAM KEMPOWELD 5500W 1
9592136 FILTER 1
9761302 PROTECTION SWITCHES'LEVER 2
9772523 FUSE 4A DELAYED 5X20 1
9772526 FUSE 8A DELAYD 5 X 20 1
