Kemppi 3200 Technical & Service Manual

WIRE 200
7.11.2002/V217201 3144540/1921770
Order no. Part Description Pc.
4279550
A
001
CARD A001 WIRE, KEMPOMAT 1
4280180
C001
CAPACITOR 0.1 UF / 250V 1
9754156
RW101
POTENTIOMETER 100 KOHM CERMET 1
9754141
RW102
POTENTIOMETER 10 KOHM CERMET 1
9761375
S001
LEVER SWITCH 1
9770450
XW002
FEMALE CONTACT BODY 2 POLES 1
9770117
XW101
MACHINE SOCKET 10 POLES, MALE 1
9770458
XW102
PLUG 6 POLES 1
9770460
XW103
PLUG 15 POLES 1
9770460
XW104
PLUG 15 POLES 1
9771591
X001
MACHINE SOCKET 70 MALE 1
956300201
Y001
SOLENOID VALVE 1
3144220
0-000
CIRCUIT DIAGRAM WIRE 200 1
1921650
0-010
SPARE PART LIST SL-K250 1
2062070
0-020
HUB FOR WIRE REEL PROMIG 1
3133500
0-030
CLAMP PROMIG 1
4267970
0-040
BRAKE PIECE PROMIG 501, 511 1
4265820
0-050
CLAMPING NUT M16 1
4270940
0-060
PRESS SPRING PROMIG 1
9425216
0-070
WASHER D16 1
206652001
0-080
DOOR PLATE 1
9549064
0-090
SLIDE LOCK 1
9549066
0-100
CLAMP 1
2062900
0-110
PLASTIC HANDLE 26X50X217/188 1
206653001
0-120
SIDE PLATE 1
9568911
0-130
HOSE CONNECTOR R1/8-5ML 1
4290570
0-140
GUIDANCE STICKER WIRE 200 1
4296860
0-150
STICKER FOR PANEL WIRE 200, KMAT 2001, 1
4296210
0-160
STICKER KEMPOWELD WIRE 1
4279770
0-170
WIRE FEED STICKER WIRE 1
4280040
0-190
KEMPOWELD CONNEC. WIRE 2
4280050
0-200
STICKER F GAS BOTTLE 1
1026870
0-220
SAFETY FRAME F DISPL 1
4279940
0-260
FLAT CABLE L=380 1
3134270
0-280
HOSE CONNECTOR R1/8-M12 1
***ACCESSORIES****
6219200
1-020
TIMER UNIT KMW TIMER 1
3135870
2-010
LIFT HOOK PROMIG 1
9840352
2-030
PLASTIC BAG 1
