Kemppi 3200 Technical & Service Manual

WIRE 400
7.11.2002/V217401 2066790/1921560
Order no. Part Description Pc.
4279550
A
001
CARD A001 WIRE, KEMPOMAT 1
4280180
C001
CAPACITOR 0.1 UF / 250V 1
9754156
RW101
POTENTIOMETER 100 KOHM CERMET 1
9754141
RW102
POTENTIOMETER 10 KOHM CERMET 1
9761375
S001
LEVER SWITCH 1
9770450
XW002
FEMALE CONTACT BODY 2 POLES 1
9770117
XW101
MACHINE SOCKET 10 POLES, MALE 1
9770458
XW102
PLUG 6 POLES 1
9770460
XW103
PLUG 15 POLES 1
9770460
XW104
PLUG 15 POLES 1
9771591
X001
MACHINE SOCKET 70 MALE 1
9563002
Y001
SOLENOID VALVE 1
3139080
0-000
CIRCUIT DIAGRAM WIRE 400 1
1921600
0-010
SPARE PART LIST SL-K400 1
2062070
0-020
HUB FOR WIRE REEL PROMIG 1
3133500
0-030
CLAMP PROMIG 1
4267970
0-040
BRAKE PIECE PROMIG 501, 511 1
4265820
0-050
CLAMPING NUT M16 1
4270940
0-060
PRESS SPRING PROMIG 1
9425216
0-070
WASHER D16 1
2066520
0-080
DOOR PLATE WIRE 400, 550 1
9549064
0-090
SLIDE LOCK 1
9549066
0-100
CLAMP 1
2062900
0-110
PLASTIC HANDLE 26X50X217/188 1
2066530
0-120
SIDE PLATE WIRE 400, 550 1
9568911
0-130
HOSE CONNECTOR R1/8-5ML 1
3139410
0-140
WIRE PATH-WELD.STICK K400 1
3139100
0-150
STICKER FOR K400 1
4296210
0-160
STICKER KEMPOWELD WIRE 1
4279770
0-170
WIRE FEED STICKER WIRE 1
4280040
0-190
KEMPOWELD CONNEC. WIRE 2
4280050
0-200
STICKER F GAS BOTTLE 1
4296870
0-210
STICKER KMW SYNC 1
1026870
0-220
SAFETY FRAME F DISPL 1
1026880
0-230
COVER PLATE FOR DISP 1
3138810
0-240
LEFT HINGE 1
3139110
0-250
RIGHT HINGE 1
4279940
0-260
FLAT CABLE L=380 1
3116880
0-270
HOOK 1
3134270
0-280
HOSE CONNECTOR R1/8-M12 1
***ACCESSORIES****
6219100
1-010
SYNCHRONIZAT. UNIT KMW SYNC 1
6219200
1-020
TIMER UNIT KMW TIMER 1
3135870
2-010
LIFT HOOK PROMIG 1
9840352
2-030
PLASTIC BAG 1
