8 / 1923600E / 0024
English
Product Name
Operation / mounting
instruction
Wire feeder unit FEED 400 1923600
Push-pull gun´s
synchronizing unit
SYNC 400
Gas guard GG 400
Transport unit P500 4272000
Swing arm KV400 3142890
Power sources Kempomig
3200, 3200W,
4000, 4000W
1922380
Volt/Ampere metering unit MSD-1 1918610
MIG guns
PMT range
PMT 30, 40
PMT 41W, 51W
1925570
1925660
MT range
MT 32
MT 38
MT 41W
MT 51W
1925440
1925340
1925480
1925490
GENERAL
FEED400 is wire feeder unit in the KEMPOMIG product range, designed for demanding professional use.
Operation controls of the FEED400 are managed from versatile and easy to use function panel. Syner-
gic 1-knob MIG function of the FEED400 enables adjustments for MIG welding from only one control
knob. The unit has preset programs for the most common materials and gases. Plate thickness display,
connected with 1-knob MIG functions, guides the operator to find the correct welding values.
4-roll drive of wire feed mechanism ensures stable wire feed. Max. wire feed speed can be either 18 m/
min or 25 m/min. The FEED400 is designed for both liquid-cooled and gas-cooled guns.
By delivery the FEED400 is equipped for steel welding. With the unit are delivered accessories, which
make possible welding of aluminium and stainless steels. In the accessories is included also lift hook
for hanging onto boom.
= Warning
FEED 400 TECHNICAL DATA
The product meets conformity requirements for CE-marking.
Working voltage (safety voltage) 30 VAC 50/60 Hz
Rated power 150 VA
Loading capacity 60 % ED
100 % ED
400 A
310 A
Operation principle
Diameter of feed roll
Wire feed speed
I
II
4 roll drive
32 mm
0...18 m / min
0...25 m / min
Filler wires
ø Fe, Ss
ø Filler wire
ø Al
0,6...1,2 mm
0,8...1,6 mm
1,0...1,6 mm
Wire reel
max. weight
max. size
20 kg
ø 300 mm
Gun connector Euro
Operation temperature range
Storage temperature range Degree
of protection
-20...+40 °C
-40...+60 °C
IP 23C
Dimensions
length
width
height
570 mm
210 mm
440 mm
Weight 15 kg
