Page #70 background image
Master M 205, 323
Operating manual - EN
Feed rolls
The table below lists the standard feed rolls available.
Feed rolls, standard
Filler wire material Feed roll profile*
Filler wire diameter
(mm)
Drive roll code Pressure roll code
Fe, Ss, Cu (Al, MC/FC)
V-groove 0.8−0.9 W001047 W001048
1.0 W000675 W000676
1.2 W000960 W000961
MC/FC (Fe)
V-groove, knurled 1.0 W001057 W001058
1.2 W001059 W001060
1.4−1.6 W001061 W001062
Al (MC/FC, Ss, Fe, Cu)
U-groove 1.0 W001067 W001068
1.2 W001069 W001070
The table below lists the heavy-duty feed rolls available.
Feed rolls, heavy-duty
Filler wire material Feed roll profile*
Filler wire diameter
(mm)
Drive roll code Pressure roll code
Fe, Ss (MC/FC)
V-groove 0.8−0.9 W006074 W006075
1.0 W006076 W006077
1.2 W004754 W004753
MC/FC (Fe)
V-groove, knurled 1.0 W006080 W006081
1.2 W006082 W006083
1.4−1.6 W006084 W006085
(MC/FC, Ss, Fe)
U-groove 1.0 W006088 W006089
1.2 W006090 W006091
* Feed roll profiles and corresponding symbols:
Feed roll profile Symbol
V-groove
V-groove, knurled
U-groove
© Kemppi
70
1922130 / 2313
