Master M 205, 323
Operating manual - EN
5.3 Wire feeder consumables
This section lists the feed rolls and wire guide tubes available both separately and in consumable kits. The consumable
kits contain recommended feed roll and wire guide tube combinations for selected filler wire materials and diameters.
The wire feeder consumables can be ordered in Configurator.kemppi.com.
In the tables, standard refers to plastic feed rolls and heavy-duty refers to metal feed rolls. The materials mentioned first
refer to primary suitability and the materials mentioned inside brackets refer to secondary suitability.
Wire feeder consumable kits
The table below lists the recommended consumable kits for selected filler wire materials and diameters.
Wire feeder consumable kits
Filler wire material Feed roll profile*
Filler wire diameter
(mm)
Consumable kit code,
standard
Consumable kit code,
heavy-duty
Fe (MC/FC)
V-groove 0.8−0.9 F000527 F000530
1.0 F000528 F000531
1.2 F000529 F000532
Ss (Fe, Cu)
V-groove 0.8−0.9 F000533 -
1.0 F000534 -
1.2 F000535 -
MC/FC (Master M 323
only)
V-groove, knurled 1.0 F000536 F000539
1.2 F000537 F000540
1.4−1.6 F000538 F000541
Al
U-groove 1.0 F000542 -
1.2 F000543 -
Wire guide tubes
The table below lists the wire guide tubes available.
Wire guide tubes
Filler wire material Filler wire diameter (mm) Inlet guide tube Outlet guide tube
Al, Ss (Fe, MC/FC)
0.8−0.9 W007294 W011440
1.0 W007295 W011441
1.2 W007296 W011442
Fe, MC/FC
0.8−0.9 W007536 W016614
1.0 W007537 W016615
1.2 W007538 W016616
© Kemppi
69
1922130 / 2313
