MASTER MLS™ 2500, 2503, 3500, 3503, MASTERTIG MLS™ 3000, 3003, 4000, 4003 / 0606– 23© KEMPPI OY
Power source Mastertig MLS™ 3000, Mastertig MLS™ 3003
Mains voltage
3~400V –15%…+20% Mastertig MLS™ 3000
3~230V –15%…+15% Mastertig MLS™ 3003
Rated power
30% ED TIG 300A 8,4kVA
60% ED TIG 230A 5,8kVA
100% ED TIG 200A 4,7kVA
40% ED MMA 250A 9,4kVA
60% ED MMA 205A 7,3kVA
100% ED MMA 160A 5,3kVA
Connection cable/fuse
4 x 1,5S mm² – 5 m/10 A delayed Mastertig MLS™ 3000
4 x 2,5S mm² – 5 m/20 A delayed Mastertig MLS™ 3003
Welding current range
MMA 10A/20,5V...250A/30,0V
TIG 5A/10,0V...300A/22,0V
Max welding voltage 36V / 250 A
Electrode sizes to be
welded
Ø1,5...5,0mm
Open circuit voltage 80 V
Welding current control stepless
Efficiency 86 % (250A/30,0V)
Power factor 0,95 (250A/30,0 V)
Open circuit power approx. 10W
External dimensions
length 500 mm
width 180 mm
height 390 mm
(650 mm TIG power source
+ cooling unit)
Weight 22 kg
