Mastertig 2800 and 3500
1
234
6
1 Main switch S001 and welding current connectors
2 I/0-signal lamp
3 Overheat protection signal lamp
4 Dynamics adjustment
5 Current adjustment potentiometer
6 Local / remote control selection
7 Remote controller connector
5
7
Pregas time
Pause current
Postgas time
2T/4T-selection
Ignition method and process
selection
DownslopePulse frequencyContinous / pulse
welding selection,
pulse ratio
adjustment
Pulse panel
9
