Master- and Mastertig-power sources are MMA and TIG power sources designed for
demanding professional use.
Master- and Mastertig-power sources are IGBT-inverters, controlled by PWM-principle.
Operation frequency is approx. 18 kHz.
5 power source sizes are available; 1~ 140 A, 1~ 150 A, 3~ 220 A, 3~ 280 A and 3~ 350 A
General
Technical data, switches and connectors
1
2
3
1 Main switch S001 and welding current connectors
2 Overheat protection signal lamp
3 Current adj. potentiometer
Master 1400
Supply voltage 1
∼
,50/60 Hz
Connection power 20% ED
60% ED
100% ED
Supply cable/ fuses
220V –10%….240V +6%
140 A/ 6,2 kVA
105 A/ 4,4 kVA
75 A/ 2,9 kVA
3 x 1,5S / 16 A slow
Welding current range MMA
Suitable electrode sizes
Welding power adj.
15 A / 20,0 V..140 A / 25,6 V
∅
1,5…..3,25 mm
stepless
OCV
Efficiency
Idling power
Approx. 80 V
80% (140 A / 25,6V)
Approx. 10 W
Degree of protection / Casing
class
IP 23
Weight 10 kg
3
