2. INSTALLATION
2.1 Cabling the machine
Mastertig AC/DC 3500W
1
3
2
4
5
1. Cable for MMA welding
2. Return current cable
3. Remote control unit
4. Shielding gas hose
5. Water-cooled TIG torch
