Kemppi MasterTig MLS 3003 ACDC User Manual

EN
3.5 SETUPFUNCTIONS
SETUP-function Display
*C = Common: applies to all memory channels
Factory setting with a grey background
Upslope current dependency
(*C)
A1 ON The upslope time is determined by the current.
OFF The upslope time remains as set.
Downslope current
dependency (*C)
A2 ON The downslope time is determined by the current.
OFF The downslope time remains as set.
TIG Antifreeze (*C)
A3 ON TIG Antifreeze on.
OFF TIG Antifreeze o.
MMA Antifreeze (*C)
A4 ON MMA Antifreeze on.
OFF MMA Antifreeze o.
VRD (*C)
A7 ON VRD mode: idle voltage < 35 V
OFF Normal idle voltage (3000: 63 V, 3003: 58 V)
2T downslope cut off
A8 ON In 2T mode, cut o the downslope with a quick push of the start
button.
OFF Quick push has no eect.
Tacking automatics
A9 ON If welding has lasted less than 3 seconds, no downslope when
welding is stopped.
OFF Tacking automatics o.
Limitation of rate of current
rise with high currents
A10 ON If the current is over 100 A and UpSlope is 0.0 sec., there is a 0.2-
second slope from half the welding current.
OFF Current rises directly to indstillet værdi.
MMA/TIG method selection
with remote control (C*)
A12 ON TIG = the start of remote control scale.
MMA = the end of the scale.
OFF Remote control as a normal current regulator.
SearchArc On/Off
A13 ON SearchArc on.
OFF SearchArc o.
Current freeze function
A14 ON During the slope, the current can be ‘frozen’ at a certain level (4T
and Minilog) by pushing the start button.
OFF Freeze function o.
Memory channel selection with
Plus/Minus buttons (C*)
A15 ON The Plus/Minus buttons on the remote control RTC20 can be used
to select the memory channel.
OFF The buttons adjust the current.
Activation of the Plus/Minus
buttons (C*)
A16 ON The Plus/Minus remote control (RTC20) is always active.
OFF The Plus/Minus remote control is active only when selected by
pressing the REMOTE button.
Water cooler flow guard (C*)
A17 ON Flow guard on.
OFF Flow guard o.
Water cooler automatic control
(C*)
A19 ON Automatic control on.
OFF Water cooler runs constantly.
Water cooler temperature
guard (C*)
A20 ON Water cooler temperature guard selected.
OFF Temperature guard o.
Automatic remote control
device recognition (C*)
A21 ON Automatic recocnition on, control cannot be selected if it is not
connected.
OFF Automatic recocnition On/O. Controller can be selected even if it
is not connected.
Tail arc
A22 ON* Tail arc on. * 4T LOG
OFF** Tail arc o. ** MINILOG
18
MasterTig MLS 3000, 3003 ACDC / © Kemppi Oy / 1112
