6. TECHNICAL DATA
Power source MasterTIG MLS™ 3000 ACDC
Connection voltage
50/60 Hz 3~400 V -10 %…+10 %
Rated power at maximum current
TIG 13.3 kVA
MMA 14.4 kVA
Connection cable
H07RN-F 4G2.5 (5 m)
Fuse, delayed
16 A
Load capacity 40 °C
40 % ED TIG 300 A/13.3 kVA
60 % ED TIG 230 A/9.8 kVA
100 % ED TIG 190 A/7.9 kVA
40 % ED MMA 250 A/14.4 kVA
60 % ED MMA 230 A/13.3 kVA
100 % ED MMA 190 A/11.0 kVA
Welding range
TIG 3 A/10.0 V-300 A/22 V
MMA 10 A/20.5 V-250 A/30 V
Max. welding voltage
MMA 45 V/250 A
Open circuit voltage
63 V DC (VRD: 35 V DC)
Idle power
TIG < 13 W
MMA 190 W
Power factor at max. current
0.62
Efficiency at max. current
83 %
80 %
Striking voltage
Up = 10 kV
Stick electrode
ø 1.5...5.0 mm
External dimensions
LxWxH 500x180x390 mm
height 650 mm (power source + cooling unit)
Weight
23 kg
Power source and cooling unit
EMC-class
A
Degree of protection
IP23S
Operating temperature
-20 °C .... +40 °C
Storage temperature
-20 °C .... +60 °C
Recommended generator
S
min
15 kVA
22
MasterTig MLS 3000, 3003 ACDC / © Kemppi Oy / 1112
