Kemppi Minarc 220 User Manual

EN
TIG 35 % ED 220 A/18.8 V
100 % ED 160 A/16.4 V
Welding range
MMA 10 A/20.4 V – 220 A/28.8 V
TIG 10 A/10.4 V – 220 A/18.8 V
Open circuit voltage
MMA 85 V (30 V in the VRD version)
TIG 60 V (30 V in the VRD version)
Idle power
MMA 40 W
Power factor at 100% ED
TIG 0.92
MMA 0.91
Efficiency at 100% ED
TIG 0.80
MMA 0.86
Stick electrodes
MMA ø 1.5–5.0 mm
External dimensions (L × W × H)
400 × 180 × 340
Weight
9.2 kg (10.2 kg with connector cable)
Temperature class
H (B)
Degree of protection
IP23S
EMC class
A
Minimun short circuit power S
sc
of
supply network*
1.6 MVA
Operating temperature range
-20 °C ... +40 °C
Storage temperature range
-40 °C ... +60 °C
Recommended generator
> 15 kVA
* See paragraph 2.3.
13
Minarc 220 / © Kemppi Oy / 1117
