3.5 SETUPFUNCTIONS
SETUP-function Display *C = Common: applies to all memory channels
Factory setting with a grey background
Upslope current dependency (*C)
A1 ON The upslope time is determined by the current.
OFF The upslope time remains as set.
Downslope current dependency (*C)
A2 ON The downslope time is determined by the current (the
user may set the slope gradient).
OFF The downslope time remains as set.
TIG Antifreeze (*C)
A3 ON TIG Antifreeze on.
OFF TIG Antifreeze o.
MMA Antifreeze (*C)
A4 ON MMA Antifreeze on.
OFF MMA Antifreeze o.
VRD (*C)
A7 ON VRD mode: idle voltage < 35 V
OFF Normal idle voltage
2T downslope cut off
A8 ON In 2T mode, cut o the downslope with a quick push of
the start button.
OFF Quick push has no eect.
Tacking automatics
A9 ON If welding has lasted less than 3 seconds, no downslope
when welding is stopped.
OFF Tacking automatics o.
Limitation of rate of current rise with
high currents
A10 ON If the current is over 100 A and UpSlope is 0.0 sec., there is
a 0.2-second slope from half the welding current.
OFF Current rises directly to maximum.
MMA/TIG method selection with
remote control (C*)
A12 ON TIG = the start of remote control scale.
MMA = the end of the scale.
OFF Remote control as a normal current regulator.
SearchArc On/Off
A13 ON SearchArc on.
OFF SearchArc o.
Current freeze function
A14 ON During the downslope, the current can be ‘frozen’ at a
certain level by pushing the start button.
OFF Freeze function o.
Memory channel selection with Up/
Down buttons (C*)
A15 ON The Plus/Minus buttons on the remote control can be used
to select the memory channel.
OFF The buttons adjust the current.
Activation of the Plus/Minus buttons
(C*)
A16 ON The Plus/Minus remote control is always active.
OFF The Plus/Minus remote control is active only when
selected by pressing the REMOTE button.
Water cooler flow guard (C*)
A17 ON Flow guard on.
OFF Flow guard o.
Water cooler automatic control (C*)
A19 ON Automatic control on.
OFF Water cooler runs constantly.
Water cooler temperature guard (C*)
A20 ON Water cooler temperature guard selected.
OFF Temperature guard o.
Automatic remote control device
recognition (C*)
A21 ON Automatic recocnition on, control cannot be selected if it
is not connected.
OFF Automatic recocnition On/O. Controller can be selected
even if it is not connected.
Tail arc
A22 ON* Tail arc on. * 4T LOG
OFF** Tail arc o. ** MINILOG
17
MasterTig MLS 2300 ACDC / © Kemppi Oy / 1112
