Kemppi MLS 2300 ACDC Operating Manual

EN
6. TECHNICAL DATA
Power source Mastertig MLS™ 2300 ACDC
Connection voltage
1~230 V –15%…+15%
Rated power
40% ED TIG
230 A 5,7 kVA
60% ED TIG
200 A 4,8 kVA
100% ED TIG
170 A 3,9 kVA
40% ED MMA
180 A 6,0 kVA
60% ED MMA
150 A 4,8 kVA
100% ED MMA
120 A 3,7 kVA
Connection cable
H07RN-F 3G2.5 (3.3 m)
Fuse (delayed)
15 A
Welding current range
TIG 3 A / 10,0 V...230 A / 19,2 V
MMA 10 A / 20,5 V...180 A / 27,2 V
Max welding voltage
32 V / 180 A (MMA)
Electrode sizes to be welded
Ø 1,5...4,0 mm
Open circuit voltage, max.
58 V
Welding current adjustment
stepless
Efficiency at nominal values
82 % (180 A / 27,2 V),
78 % (230 A / 19,2 V)
Power factor
at nominal values
0,99
Open circuit power
TIG 6 W
MMA 180 W
External dimensions
LxWxH 430 x 180 x 390 mm
height 650 mm (power source + cooling unit)
Weight
15 kg
Cooling unit (TIG-welding) Mastercool 20
Connection voltage
230 V -15 %...+15 %
Connection capacity
100 % ED 50 W
Cooling power
1,0 kW
Start pressure, max
4,0 bar
Cooling liquid
20 % - 40 % glycol-water
Reservoir volume
approx. 3 l
External dimensions
LxWxH 500 x 180 x 260 mm
Weight
8 kg
21
MasterTig MLS 2300 ACDC / © Kemppi Oy / 1112
