Kemppi Pro Evolution 3200 - 9 Technical Data

14 – Kemppi pro evolution 3200, 4200, 5200, 3200 mvu, 4200 mvu, 5200 mvu / 0617 © Kemppi oy
9. technIcal data
Pro Evolution 3200 Pro Evolution 4200 Pro Evolution 5200
Mains voltage
3~50/60 Hz 400 V -15%...+20% 400 V -15%...+20% 400 V -15%...+20%
Rated power
80 % ED 420 A / 19,7 kVA 520 A / 26,6 kVA
100 % ED 320 A / 13,3 kVA 400 A / 18,6 kVA 440 A / 20,0 kVA
Connection cable/
fuse delayed 4 x 6 S - 5 m / 25 A 4 x 6S - 5 m /35 A 4 x 6S - 5 m / 35 A
Max. welding voltage 40
0
C
70 % ED 520 A / 40,0 V
80 % ED 420 A / 36,8 V
100 % ED 320 A / 32,8 V 400 A / 36 V 440 A / 37,6 V
Max. welding voltage 20
0
C
100 % ED 320 A / 32,8 V 420 A / 36,8 V 480 A / 39,6 V
Welding current range
MMA 10 A ... 320 A 10 A ... 420 A 10 A ... 520 A
TIG 5 A ... 320 A 5 A ... 420 A 5 A ... 520 A
MIG 12 V ... 37 V 12 V ... 39 V 12 V ... 42 V
Max. welding voltage 46 V / 300 A 46 V / 400 A 50 V / 500 A
Open circuit voltage appr. 65 V appr. 65 V appr. 65 V
Open circuit power < 75 W < 75 W < 75 W
Efciency
at nominal values appr. 85 % appr. 85 % appr. 85 %
Power factor
at nominal values appr. 0,93 appr. 0,93 appr. 0,93
Storage temperature
range -40 ... +60
0
C -40 ... +60
0
C -40 ... +60
0
C
Operating
temperature range -20 ... +40
0
C -20 ... +40
0
C -20 ... +40
0
C
Temperature class H (180
0
C) / B (130
0
C) H (180
0
C) / B (130
0
C) H (180
0
C) / B (130
0
C)
Degree of protection IP 23 C IP 23 C IP 23 C
Extemal dimensions
length 530 mm 530 mm 530 mm
width 230 mm 230 mm 230 mm
height 520 mm 520 mm 520 mm
Weight 37 kg 41 kg 48 kg
Voltage supply for
auxiliary devices 50 V DC 50 V DC 50 V DC
X 14, X 15 fuse 6,3 A delayed fuse 6,3 A delayed fuse 6,3 A delayed
Voltage supply for cooling unit
PROCOOL 10 1~, 230 V / 250 VA 1~, 230 V / 250 VA 1~, 230 V / 250 VA
X 16 fuse 1,0 A delayed fuse 1,0 A delayed fuse 1,0 A delayed
