Bobbin Winding
oRemoving bobbin case
Remove the extension table from the machine by pulling
it to the left. Open the shuttle cover_,_l)by pulling down
the embossed part on the left of the cover.
Raise the needle to its highest position by rotating the
handwheel toward you.
,,"13Shuttle cover
_2_,Bobbin case
/,>,
To remove the bobbin case _2_from the shuttle, pull open
the latch of the bobbin case. Pull the bobbin case straight
out of the shuttle.
Bobbin winding
[] Release the clutch by pulling out the handwheel. This
will stop the needle from moving while you wl
bobbin.
[]
[] Draw thread
[] Guide the the bobbi !ing tension
disc.
[] Thread through the inside to
the outside.
::5_Put the bobbin on the spindle.
[]
18
