Kenwood DMX5020DABS User Manual

USB
15English
USB
Connecting a USB device
1 Connect the USB device with the USB
cable. (P.48)
2 Press the [HOME] button.
3 Touch [ ].
4 Touch [USB]. (P.9)
Ñ Disconnect the USB device
1 Press the [HOME] button.
2 Touch [ ].
3 Touch a source other than [USB].
4 Detach the USB device.
Ñ Usable USB device
You can use a mass-storage-class USB device on
this unit.
The word “USB device” appearing in this manual
indicates a flash memory device.
● About file system
The file system should be the one of the
following.
• FAT16 • FAT32 • exFAT
NOTE
• Install the USB device in the place where it will
not affect safe driving.
• You cannot connect a USB device via a USB hub
and Multi Card Reader.
• Take backups of the audio files used with this
unit. The files can be erased depending on the
operating conditions of the USB device.
We shall have no compensation for any damage
arising from any erased data.
USB Basic Operation
Most functions can be controlled from the
source control screen and playback screen.
Control screen
4
52
6
17
3
Open the drawer
54
1
[ ] / [ ]
• [
] : Repeats the current track/folder. Each
time you touch the key, repeat mode switches
in the following sequence;
File repeat ([
]), Folder repeat ([ ]), Repeat
all ([
])
• [
] : Randomly plays all tracks in current
folder. Each time you touch the key, random
mode switches in the following sequence;
File random ([
]), Random off ([ ])
2
Track information
Displays the information of the current file.
Only a file name and a folder name are
displayed if there is no tag information.
!B5H-0358-07_DMX_E_En.indb 15 2020/09/15 13:45

Kenwood DMX5020DABS Specifications

General

DIN size	2 DIN
Output power	- W
Product color	Black
Ready for iPod	Yes
Disc types supported	No
Audio output channels	- channels
