PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
101
DNX4280BT/5180/5280BT/5380/5380M
/5380BT/5580BT/6040EX/6180/6480BT/6980
K: DNX6980 K1: DNX6180 K2: DNX6040EX K3: DNX5180 (North America)
E1: DNX5280BT E2: DNX4280BT (Europe) Q1: DNX5580BT (Russian)
R1: DNX6480BT (Latin America) X1: DNX5380BT (Australia)
C1: DNX5380 (China) M1: DNX5380 M2: DNX5380M (Other Areas)
D914 B30-1779-05 LED (1608_SR) E1Q1X1
D914 B30-1779-05 LED (1608_SR) M1M2C1
D916 B30-1779-05 LED (1608_SR) E1Q1X1
D916 B30-1779-05 LED (1608_SR) M1M2C1
C900 CK73HB0J105K CHIP C 1.0UF K E1Q1X1
C900 CK73HB0J105K CHIP C 1.0UF K M1M2C1
C901-903 CK73HB1H102K CHIP C 1000PF K E1Q1X1
C901-903 CK73HB1H102K CHIP C 1000PF K M1M2C1
C904 CK73FB0J226M CHIP C 22UF M E1Q1X1
C904 CK73FB0J226M CHIP C 22UF M M1M2C1
C905 CK73HB1E103K CHIP C 0.010UF K E1Q1X1
C905 CK73HB1E103K CHIP C 0.010UF K M1M2C1
C906 CK73HB1A104K CHIP C 0.10UF K E1Q1X1
C906 CK73HB1A104K CHIP C 0.10UF K M1M2C1
C907 CK73GB0J106M CHIP C 10UF M E1Q1X1
C907 CK73GB0J106M CHIP C 10UF M M1M2C1
C908 CK73GB1H104K CHIP C 0.10UF K X1M1M2
C908 CK73GB1H104K CHIP C 0.10UF K C1
CN900
✽
E41-3287-05 FLAT CABLE CONNECTOR E1Q1X1
CN900
✽
E41-3287-05 FLAT CABLE CONNECTOR M1M2C1
CN901
✽
E41-2715-05 PIN ASSY X1M1M2
CN901
✽
E41-2715-05 PIN ASSY C1
J900
✽
QNS0288-003 DIA 3.5 TYPE JACK E1Q1X1
J900
✽
QNS0288-003 DIA 3.5 TYPE JACK M1M2C1
J901 E58-1129-05 RECTANGULAR RECEPTACLE X1M1M2
J901 E58-1129-05 RECTANGULAR RECEPTACLE C1
L902-905 L92-0172-05 CHIP FERRITE
E1Q1X1
L902-905 L92-0172-05 CHIP FERRITE M1M2C1
R900 RK73HB1J101J CHIP R 100 J 1/16W E1Q1X1
R900 RK73HB1J101J CHIP R 100 J 1/16W M1M2C1
R901 RK73HB1J822J CHIP R 8.2K J 1/16W E1Q1X1
R901 RK73HB1J822J CHIP R 8.2K J 1/16W M1M2C1
R902 RK73HB1J223J CHIP R 22K J 1/16W E1Q1X1
R902 RK73HB1J223J CHIP R 22K J 1/16W M1M2C1
R905 RK73HH1J361D CHIP R 360 D 1/16W E1Q1X1
R905 RK73HH1J361D CHIP R 360 D 1/16W M1M2C1
R906 RK73HB1J392J CHIP R 3.9K J 1/16W E1Q1X1
R906 RK73HB1J392J CHIP R 3.9K J 1/16W M1M2C1
R907 RK73HB1J471J CHIP R 470 J 1/16W E1Q1X1
R907 RK73HB1J471J CHIP R 470 J 1/16W M1M2C1
R911 RK73GB2A221J CHIP R 220 J 1/10W E1Q1X1
R911 RK73GB2A221J CHIP R 220 J 1/10W M1M2C1
R912,913 RK73HB1J512J CHIP R 5.1K J 1/16W E1Q1X1
R912,913 RK73HB1J512J CHIP R 5.1K J 1/16W M1M2C1
R914 RK73GB2A4R7J CHIP R 4.7 J 1/10W E1Q1X1
R914 RK73GB2A4R7J CHIP R 4.7 J 1/10W M1M2C1
S900-905 S70-0960-05 TACT SWITCH E1Q1X1
S900-905 S70-0960-05 TACT SWITCH M1M2C1
S906 T99-0484-05 ROTARY ENCODER E1Q1X1
S906 T99-0484-05 ROTARY ENCODER M1M2C1
D900
✽
VR1005AAA270 VARISTOR E1Q1X1
D900
✽
VR1005AAA270 VARISTOR M1M2C1
D902,903 NSSM065T-X LIGHT EMITTING DIODE E1Q1X1
D902,903 NSSM065T-X LIGHT EMITTING DIODE M1M2C1
D908 NSSM065T-X LIGHT EMITTING DIODE E1Q1X1
D908 NSSM065T-X LIGHT EMITTING DIODE M1M2C1
D915
✽
VR1005DDA080 VARISTOR E1Q1X1
D915
✽
VR1005DDA080 VARISTOR M1M2C1
D918,919
✽
VR1005AAA270 VARISTOR E1Q1X1
D918,919
✽
VR1005AAA270 VARISTOR M1M2C1
IC900 PIC95603 ANALOGUE IC E1Q1X1
IC900 PIC95603 ANALOGUE IC M1M2C1
D216 B30-1779-05 LED (1608_SR) E1Q1X1
D216 B30-1779-05 LED (1608_SR) M1M2C1
CN1 E41-2985-05 FLAT CABLE CONNECTOR E1Q1X1
CN1 E41-2985-05 FLAT CABLE CONNECTOR M1M2C1
CN2
✽
E41-2715-05 PIN ASSY X1M1M2
CN2
✽
E41-2715-05 PIN ASSY C1
CN200
✽
E41-3265-05 FLAT CABLE CONNECTOR E1Q1X1
CN200
✽
E41-3265-05 FLAT CABLE CONNECTOR M1M2C1
CN201 E41-2741-05 PIN ASSY X1M1M2
CN201 E41-2741-05 PIN ASSY C1
J1 ,2
✽
E59-0863-05 RECTANGULAR PLUG E1Q1X1
J1 ,2
✽
E59-0863-05 RECTANGULAR PLUG M1M2C1
J200,201
✽
E58-1143-05 RECTANGULAR RECEPTACLE E1Q1X1
J200,201
✽
E58-1143-05 RECTANGULAR RECEPTACLE M1M2C1
R2 RK73GB2A000J CHIP R 0.0 J 1/10W E1Q1X1
R2 RK73GB2A000J CHIP R 0.0 J 1/10W M1M2C1
R210 RK73GB2A000J CHIP R 0.0 J 1/10W E1Q1X1
R210 RK73GB2A000J CHIP R 0.0 J 1/10W M1M2C1
R212 RK73GB2A131J CHIP R 130 J 1/10W E1Q1X1
R212 RK73GB2A131J CHIP R 130 J 1/10W M1M2C1
S200 S68-0880-05 PUSH SWITCH E1Q1X1
S200 S68-0880-05 PUSH SWITCH M1M2C1
D2
✽
VR1005DDA080 VARISTOR E1Q1X1
D2
✽
VR1005DDA080 VARISTOR M1M2C1
D3 ,4
✽
VR1005AAA270 VARISTOR E1Q1X1
D3 ,4
✽
VR1005AAA270 VARISTOR M1M2C1
D5
✽
VR1005DDA080 VARISTOR E1Q1X1
D5
✽
VR1005DDA080 VARISTOR M1M2C1
D11 -14
✽
VR1005DDA080 VARISTOR E1Q1X1
D11 -14
✽
VR1005DDA080 VARISTOR M1M2C1
D16 -18
✽
VR105C3R3BAA VARISTOR E1Q1X1
D16 -18
✽
VR105C3R3BAA VARISTOR M1M2C1
D19 ,20
✽
VR1005AAA270 VARISTOR E1Q1X1
D19 ,20
✽
VR1005AAA270 VARISTOR M1M2C1
D21
✽
VR1005DDA080 VARISTOR E1Q1X1
D21
✽
VR1005DDA080 VARISTOR M1M2C1
D25
✽
VR1005DDA080 VARISTOR E1Q1X1
D25
✽
VR1005DDA080 VARISTOR M1M2C1
D201
✽
VR1005DDA080 VARISTOR E1Q1X1
PROCESSOR UNIT (X17-213x-xx)
SWITCH UNIT (X16-716x-xx)

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
