16
DNX4280BT/5180/5280BT/5380/5380M
/5380BT/5580BT/6040EX/6180/6480BT/6980
TEST MODE
1 General information
1.1 Purpose
The purpose of this document is to define the items re-
quired for the test mode used at the manufacturing process
and service stations for 11 Visual Mid / Entry model.
1.2 Scope of application
This document is applied for the models described in Table
1.2.1. (This document also describes the presence or ab-
sence of the functions related to the Test mode.)
1.3 Outline
This section describes the Test mode of the 11 Visual Mid/
Entry model regarding the display specifi cations, the speci-
fi cations of the operation with the key remote controller, and
the details of its behavior.
2 Test Mode specifi cation
2.1 Operations
The system can be transferred to the Test mode with the
following two approaches:
Regardless of the ON/OFF status of security, the system
can be transferred to the Test mode with one of the follow-
ing operations.
q
Start the system by pressing [Reset] key while pressing
the following keys.
Mid : [MENU] + [ATT]
Entry : [Eject] + [SCRN]
w
Input [2]
→
[
]
→
[3] with the remote controller (SW:
AUD) into the standby source.
Model
type
Desti-
nation
Model Name
Panel
mecha-
nism
Attachable/
detachable
panel
BT
Built-in
Ext SW
Electro-
static
touch
DivX KAB I/F DSP
Steering
Remote
TMC
Tuner
SD Slot
DNX
(Mid)
K DNX7180
c°ccc°cc°cc
R DNX7480BT
c°cccc°c°°c
E DNX7280BT
cccccccc°cc
M DNX7380BT
cccccc°cccc
M2 DNX7380BTM
cccccc°cc°c
X DNX7380BT
cccccc°cc°c
DNX
(Entry)
K DNX6980
°°c°°°c°°cc
K DNX6180
°°c°°°c°°c°
K2 DNX6040EX
°°c°°°c°°c°
R DNX6480BT
°°c°°c°°°°c
E DNX5280BT
°cc°°cc°°cc
Q DNX5580BT
°cc°°c°°°cc
X DNX5380BT
°cc°°c°°c°c
ER DNX4280BT
°°c°°c°°°c°
K DNX5180
°°°°°°c°°°°
M DNX5380
°c°°°cc°ccc
M2 DNX5380M
°c°°°cc°c°c
V DNX5380
°c°°°cc°c°c
Table 1.2.1 Model List of 11 Visual Mid/Entry model
While in the test mode, fl ash ILLUMI of the EJECT port in 1
sec intervals regardless of the panel position (only Mid).
In the Test mode, the LED for SI fl ickers at regular intervals.
Panel: Flash (all models)
Sub panel: Turn off when panel is attached. Flash when
panel is detached. (Only for attachable/de-
tachable model)
When starting in the Test mode, the illumi is turned ON in
white.
Turn the system OFF in 30 minutes when it is started in the
Test mode.
Continue the test mode by ACC OFF/ON. Clear the test
mode by Reset.
2.2 Specifi cation of screens
This section describes the Test mode functions available
in each screen. (The screen layout may differ from the real
system.)
To Next Page
