Kenwood DNX5280BT Service Manual

15
DNX4280BT/5180/5280BT/5380/5380M
/5380BT/5580BT/6040EX/6180/6480BT/6980
Truth value table
q
Destination setting (54pin: Type0, 55pin: Type1, 56pin: Type2)
Destination TYPE2 TYPE1 TYPE0
DNX4/5/6 (Entry)
K (eXcelon)/K/K2/R/ER (FIX)
0
00
E/Q (TDF) 0 1
M/M2/V/X (TDF/Swichable) 1 0
Not used 1 1
DNX7 (Mid)
K (eXcelon)/K/K2/R/ER (FIX)
1
00
E/Q/M/M2/V/X (TDF) 0 1
Not used 1 0
Not used 1 1
Pin No. Pin Name I/O Application
Truth value
table
Processing / Operation / Description
75 MST_SDA I/O MSTAR_SI2C_data 100k Other restrictions apply
76 MST_SCL O MSTAR_SI2C_clock 100k Other restrictions apply
77 MST_WP I/O MST7912 external fl ash WRITE protection
In normal operation: Input
Hi: MST_I2C command transmission stop
When writing-in adjustment value: Output
Hi: WRITE protection cancel
78,79 NC -
80 SRC I At PON only Hi: ON
81 EJECT I At PON only Hi: ON
82,83 NC -
84 IPOD_AVIN (NC) -
85 ILL_R O Blinking Test_Mode: Blinking, Hi: ON
86 KEY I KEY for Entry
87 Y1 O For touch panel control
88 Y0 O For touch panel control
89 X1 O For touch panel control
90 X0 O For touch panel control
91 YDATA_D I For touch panel control
92 XDATA_D I For touch panel control
93 YDATA_U I For touch panel control
94 AVSS -
95 XDATA_U I For touch panel control
96 VREF -
97 AVCC -
98 PULL_UP_ON O For touch panel control
99 TP_PRESS O For touch panel control
100 NC -
MICROCOMPUTER’S TERMINAL DESCRIPTION

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
