Kenwood DNX5280BT Service Manual

88
DNX4280BT/5180/5280BT/5380/5380M
/5380BT/5580BT/6040EX/6180/6480BT/6980
3
2
1
FE
(X16-706)
(X35-)
DC2
DC1
SIZE AAA BATTERY
(NOT SUPPLIED)
RC1
C
G
L
M
N
: N09-6848-15
: N82-2007-47
: N09-6489-05
: N09-6849-05
: N09-6850-05
210
x2
C
x2
Cx2
(X15-154 C/3)
M
C
C
M
799
770
776
244
254
PA1
290
293
292
285
284
206
255
296
277
295
301
257
294
274
245
291
272
LCD1
298
271
FC6
259
D
M
D
D
C
775
749
786
Depends on the models. Refer to the parts list.
EXPLODED VIEW (DISPLAY ASSY): DNX4280BT/5180/6040EX/6180/6480BT/6980
Parts with the exploded numbers larger than 700 are not supplied.

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
