PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
91
DNX4280BT/5180/5280BT/5380/5380M
/5380BT/5580BT/6040EX/6180/6480BT/6980
K: DNX6980 K1: DNX6180 K2: DNX6040EX K3: DNX5180 (North America)
E1: DNX5280BT E2: DNX4280BT (Europe) Q1: DNX5580BT (Russian)
R1: DNX6480BT (Latin America) X1: DNX5380BT (Australia)
C1: DNX5380 (China) M1: DNX5380 M2: DNX5380M (Other Areas)
260 1D
✽
W02-5479-35 NAVIGATION MODULE M1M2C1
264 2C
✽
X34-6950-10 ELECTRIC UNIT K
264 2C
✽
X34-6950-11 ELECTRIC UNIT K1K2
264 2C
✽
X34-6950-12 ELECTRIC UNIT K3
264 2C
✽
X34-6950-21 ELECTRIC UNIT M1
264 2C
✽
X34-6950-22 ELECTRIC UNIT M2
264 2C
✽
X34-6950-71 ELECTRIC UNIT X1
264 2C
✽
X34-6952-71 ELECTRIC UNIT E1
264 2C
✽
X34-6952-72 ELECTRIC UNIT E2
264 2C
✽
X34-6953-01 ELECTRIC UNIT C1
264 2C
✽
X34-6953-21 ELECTRIC UNIT R1
264 2C
✽
X34-6953-81 ELECTRIC UNIT Q1
265 2D
✽
X88-2080-10 DIGITAL I/O UNIT KK1K2
265 2D
✽
X88-2080-10 DIGITAL I/O UNIT R1E1E2
265 2D
✽
X88-2080-10 DIGITAL I/O UNIT Q1K3
265 2D
✽
X88-2080-21 DIGITAL I/O UNIT X1M1M2
265 2D
✽
X88-2080-21 DIGITAL I/O UNIT C1
VME1 1D
✽
X92-6640-00 DVD MECHANISM ASSY (DVS-8710W)
268 2F
✽
A46-1919-11 REAR COVER E1Q1X1
268 2F
✽
A46-1919-11 REAR COVER M1M2C1
PA1 3E
✽
A64-5199-21 PANEL E1
PA1 3E
✽
A64-5200-21 PANEL Q1
PA1 3E
✽
A64-5201-21 PANEL X1
PA1 3E
✽
A64-5202-21 PANEL M1M2C1
PA1 3E
✽
LV11752-047A F. PANEL ASSY K3
PA1 3E
✽
LV11752-048A F. PANEL ASSY E2
PA1 3E
✽
LV11752-049A F. PANEL ASSY K1
PA1 3E
✽
LV11752-050A F. PANEL ASSY K2
PA1 3E
✽
LV11752-051A F. PANEL ASSY R1
PA1 3E
✽
LV11752-052A F. PANEL ASSY K
271 1E B09-0548-13 CAP K
271 1E
✽
B09-1005-03 CAP R1
272 3E B43-1518-04 BADGE
273 1E
✽
LV22871-003A CAP (USB) X1M1M2
273 1E
✽
LV22871-003A CAP (USB) C1
274 3E
✽
LV22872-001A ESCUTCHEON
277 3E
✽
LV39104-001A REMO LENS
LCD1 3F B38-1223-15 LCD
FC5 2F
✽
E39-1199-05 FLAT CABLE E1Q1X1
FC5 2F
✽
E39-1199-05 FLAT CABLE M1M2C1
FC6 2E
✽
E39-1200-05 FLAT CABLE
WH2 2E
✽
E39-1217-05 WIRING HARNESS X1M1M2
WH2 2E
✽
E39-1217-05 WIRING HARNESS C1
279 1F
✽
F07-2240-03 COVER E1Q1X1
279 1F
✽
F07-2240-03 COVER M1M2C1
280 3F F09-2970-04 SHEET E1Q1X1
280 3F F09-2970-04 SHEET M1M2C1
281 1F
✽
G01-4780-04 COMPRESSION SPRING E1Q1X1
281 1F
✽
G01-4780-04 COMPRESSION SPRING M1M2C1
282 2F
✽
G02-1919-04 FLAT SPRING E1Q1X1
282 2F
✽
G02-1919-04 FLAT SPRING M1M2C1
284 3E G16-1749-04 SHEET
285 3E G16-1771-04 SHEET
288 3F
✽
K24-5092-04 PUSH KNOB (RELEASE) E1Q1X1
288 3F
✽
K24-5092-04 PUSH KNOB (RELEASE) M1M2C1
290 3E
✽
LV22869-005A BUTTON (AUD) R1E1E2
290 3E
✽
LV22869-005A BUTTON (AUD) Q1X1M1
290 3E
✽
LV22869-005A BUTTON (AUD) M2C1
290 3E
✽
LV22869-006A BUTTON (AUD) KK1K2
290 3E
✽
LV22869-006A BUTTON (AUD) K3
291 3E
✽
LV22870-004A BUTTON (SCRN)
292 3E
✽
LV39102-003A BUTTON (MENU)
293 3E
✽
LV39103-004A BUTTON (NAV)
294 3E
✽
LV39106-002A KNOB (VOL)
295 3E
✽
LV39226-001A BUTTON (EJECT)
296 3E
✽
LV39227-001A BUTTON (RESET)
C 1E
✽
N09-6848-15 TAPTITE SCREW
G 1F N82-2007-47
BINDING HEAD TAPTITE SCREW E1Q1X1
G 1F N82-2007-47 BINDING HEAD TAPTITE SCREW M1M2C1
L 1F N09-6489-05 MACHINE SCREW (M2.0X3.0) E1Q1X1
L 1F N09-6489-05 MACHINE SCREW (M2.0X3.0) M1M2C1
M 1F
✽
N09-6849-05 TAPTITE SCREW KK1K2
M 1F
✽
N09-6849-05 TAPTITE SCREW R1E2K3
N 1F
✽
N09-6850-05 TAPTITE SCREW E1Q1X1
N 1F
✽
N09-6850-05 TAPTITE SCREW M1M2C1
298 3F
✽
S79-0879-05 SWITCH ASSY
301 2F
✽
X35-5140-10 VIDEO UNIT KK1K2
301 2F
✽
X35-5140-10 VIDEO UNIT R1E2K3
301 2E
✽
X35-5140-21 VIDEO UNIT X1M1M2
301 2E
✽
X35-5140-21 VIDEO UNIT C1
301 2E
✽
X35-5142-71 VIDEO UNIT E1Q1
C1 CK73GB1H104K CHIP C 0.10UF K
C2 C90-5670-05 ELECTRO 2200UF 16WV
C3 ,4 CK73GB1H104K CHIP C 0.10UF K
C5 CE32BM1E101M CHIP EL 100UF 25WV
C6 CK73HB1E103K CHIP C 0.010UF K
C7 ,8 CK73GB1H104K CHIP C 0.10UF K
C9 CK73HB1E103K CHIP C 0.010UF K
C10 ,11 CK73EB1E106K CHIP C 10UF K
C12 CK73GB1H104K CHIP C 0.10UF K
C13 CK73HB1E103K CHIP C 0.010UF K
C14 CK73FB1E475K CHIP C 4.7UF K
C15 CK73GB1H104K CHIP C 0.10UF K
C16 CK73HB1E223K CHIP C 0.022UF K
C17 CK73HB1H221K CHIP C 220PF K
C18 CK73HB1H472K CHIP C 4700PF K
C19 CC73HCH1H151J CHIP C 150PF J
C21 CK73EB1E106K CHIP C 10UF K
C22 CK73GB1H104K CHIP C 0.10UF K
C23 C92-2031-05 ELECTRO 220UF
C24 CK73HB1A104K CHIP C 0.10UF K
C25 CK73HB1E103K CHIP C 0.010UF K
C26 CK73FB0J226M CHIP C 22UF M
C27 CK73GB1H104K CHIP C 0.10UF K
DISPLAY ASSY
VIDEO CONTROL UNIT (X15-154x-xx)
DNX4280BT/5180/5280BT/5380/5380M/5380BT/5580BT
DNX6040EX/6180/6480BT/6980

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
