Kenwood DNX5280BT Service Manual

PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
✽
New parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
90
DNX4280BT/5180/5280BT/5380/5380M
/5380BT/5580BT/6040EX/6180/6480BT/6980
K: DNX6980 K1: DNX6180 K2: DNX6040EX K3: DNX5180 (North America)
E1: DNX5280BT E2: DNX4280BT (Europe) Q1: DNX5580BT (Russian)
R1: DNX6480BT (Latin America) X1: DNX5380BT (Australia)
C1: DNX5380 (China) M1: DNX5380 M2: DNX5380M (Other Areas)
203 1C
✽
A22-3301-21 SUB PANEL ASSY E1Q1X1
203 1C
✽
A22-3301-21 SUB PANEL ASSY M1M2C1
205 1D
✽
A52-1160-02 TOP PLATE
RC1 1E A70-2107-05
REMOTE CONTROLLER AS (RC-DV331) KR1Q1
RC1 1E A70-2107-05 REMOTE CONTROLLER AS (RC-DV331) X1M1M2
RC1 1E A70-2107-05 REMOTE CONTROLLER AS (RC-DV331) C1
-
✽
B59-2045-00 SUB-INSTRUCTION MANUAL (ENG.SPA KK1K2
-
✽
B59-2045-00 SUB-INSTRUCTION MANUAL (ENG.SPA R1K3
-
✽
B59-2046-00 SUB-INSTRUCTION MANUAL (FRE) KK1K2
-
✽
B59-2046-00 SUB-INSTRUCTION MANUAL (FRE) K3
-
✽
B59-2047-00 SUB-INSTRUCTION MANUAL (POR) R1
-
✽
B59-2048-00 SUB-INSTRUCTION MANUAL (ENG) E1E2Q1
-
✽
B59-2049-00 SUB-INSTRUCTION MA (FRE.GER.DUT E1E2
-
✽
B59-2050-00 SUB-INSTRUCTION MANUAL (RUS) Q1
-
✽
B59-2051-00 SUB-INSTRUCTION MANUAL (ENG) X1M1M2
-
✽
B59-2051-00 SUB-INSTRUCTION MANUAL (ENG) C1
-
✽
B59-2052-00 SUB-INSTRUCTION MANUAL (S-CHI) M1C1
-
✽
B59-2053-00 SUB-INSTRUCTION MANUAL (ARA) M2
-
✽
B59-2068-00 SUB-INSTRUCTION MA (ITA.SPA.POR E1E2
-
✽
B64-4795-00 INSTRUCTION MANUAL (ARA) M2
-
✽
B64-4796-00 INSTRUCTION MANUAL (S-CHI) C1
-
✽
B64-4857-00 INSTRUCTION MANUAL (ARA) M2
-
✽
B64-4859-00 INSTRUCTION MANUAL (S-CHI) C1
206 1E B07-3165-02 ESCUTCHEON
KK1K2
206 1E B07-3165-02 ESCUTCHEON R1E1E2
206 1E B07-3165-02 ESCUTCHEON Q1X1K3
206 1E B07-3165-02 ESCUTCHEON M1M2
207 1F B07-3172-12 ESCUTCHEON
X1M1M2
207 1F B07-3172-12 ESCUTCHEON C1
210 1E D10-7012-04 LEVER
KK1K2
210 1E D10-7012-04 LEVER R1E1E2
210 1E D10-7012-04 LEVER Q1K3
DC1 1E E30-6881-25 DC CORD
KK1K2
DC1 1E E30-6881-25 DC CORD R1X1K3
DC1 1E E30-6881-25 DC CORD M1M2C1
DC2 1E E30-6796-15 DC CORD (ISO) E1E2Q1
FC1 1D
✽
E39-1193-05 FLAT CABLE
FC2 2D
✽
E39-1194-05 FLAT CABLE
FC3 2D
✽
E39-1197-05 FLAT CABLE KR1
FC4 3D
✽
E39-1198-05 FLAT CABLE
WH1 3D
✽
E39-1218-05 WIRING HARNESS X1M1M2
WH1 3D
✽
E39-1218-05 WIRING HARNESS C1
217 2C
✽
F07-2239-02 COVER E1Q1X1
217 2C
✽
F07-2239-02 COVER M1M2C1
218 1D F09-2929-04 CAP (USB) KK1K2
218 1D F09-2929-04 CAP (USB) R1E1E2
218 1D F09-2929-04 CAP (USB) Q1K3
219 2C
✽
F09-3070-05 FAN
228 3C
✽
F19-1839-03 COVER (DUCT)
F1 2C F52-0024-05 FUSE (MINI BLADE TYPE) 15A
234 1C
✽
G01-4778-04 TORSION COIL SPRING E1Q1X1
234 1C
✽
G01-4778-04 TORSION COIL SPRING M1M2C1
235 1C
✽
G01-4779-04 TORSION COIL SPRING E1Q1X1
235 1C
✽
G01-4779-04 TORSION COIL SPRING M1M2C1
239 3D G16-1750-14 SHEET
-
✽
H54-4960-03 ITEM CARTON CASE K
-
✽
H54-4961-03 ITEM CARTON CASE K1
-
✽
H54-4962-03 ITEM CARTON CASE K2
-
✽
H54-4963-03 ITEM CARTON CASE R1
-
✽
H54-4964-03 ITEM CARTON CASE E1
-
✽
H54-4965-03 ITEM CARTON CASE E2
-
✽
H54-4966-03 ITEM CARTON CASE Q1
-
✽
H54-4967-03 ITEM CARTON CASE X1
-
✽
H54-4968-03 ITEM CARTON CASE K3
-
✽
H54-4969-03 ITEM CARTON CASE M1
-
✽
H54-4970-03 ITEM CARTON CASE M2
-
✽
H54-5034-03 ITEM CARTON CASE C1
241 1E H30-0595-04
ADHESIVE DOUBLE-COATED TAPE X1M1M2
241 1E H30-0595-04 ADHESIVE DOUBLE-COATED TAPE C1
244 1E J22-0657-03 MOUNTING HARDWARE ASSY
KK1K2
244 1E J22-0657-03 MOUNTING HARDWARE ASSY R1E1E2
244 1E J22-0657-03 MOUNTING HARDWARE ASSY Q1K3
245 1F J22-0964-04
MOUNTING HARDWARE (GPS PLATE)
252 3C L92-0638-05 FERRITE CORE
253 1E N35-2008-43
BINDING HEAD MACHINE SCREW E1Q1X1
253 1E N35-2008-43 BINDING HEAD MACHINE SCREW M1M2C1
254 1E N99-1779-15 SCREW SET KK1K2
254 1E N99-1779-15 SCREW SET R1X1K3
254 1E N99-1779-15 SCREW SET M1M2C1
A 3C N09-6425-15 MACHINE SCREW (M3.0X5)
B 2C N09-6821-05 MACHINE SCREW
C 2D
✽
N09-6848-15 TAPTITE SCREW
D 1D
✽
N09-6851-05 MACHINE SCREW
F 2C N35-2614-48
BINDING HEAD MACHINE SCREW
G 1C N82-2007-47 BINDING HEAD TAPTITE SCREW E1Q1X1
G 1C N82-2007-47 BINDING HEAD TAPTITE SCREW M1M2C1
H 2C N82-2608-43 BINDING HEAD TAPTITE SCREW
J N86-2606-48 BINDING HEAD TAPTITE SCREW
K 2C N86-2608-43 BINDING HEAD TAPTITE SCREW E1Q1X1
K 2C N86-2608-43 BINDING HEAD TAPTITE SCREW M1M2C1
255 1F W01-1768-15 MICROPHONE KK1K2
255 1F W01-1768-15 MICROPHONE R1E1E2
255 1F W01-1768-15 MICROPHONE Q1X1
256 1E
✽
W01-2004-05 ACCESSORIES (REMOCON CABLE) X1M1M2
256 1E
✽
W01-2004-05 ACCESSORIES (REMOCON CABLE) C1
257 1F
✽
W01-2005-05 COMPACT DISC (MANUAL)
258 1F
✽
W01-2010-05 CARRYING CASE E1Q1X1
258 1F
✽
W01-2010-05 CARRYING CASE M1M2C1
259 1E W02-5304-05 ANTENNA MODULE (GPS ANT)
260 1D
✽
W02-5475-35 NAVIGATION MODULE K1K2K3
260 1D
✽
W02-5476-35 NAVIGATION MODULE E2
260 1D
✽
W02-5477-35 NAVIGATION MODULE K
260 1D
✽
W02-5478-35 NAVIGATION MODULE E1
260 1D
✽
W02-5479-35 NAVIGATION MODULE R1Q1X1
DNX4280BT/5180/5280BT/5380/5380M/5380BT/5580BT
DNX6040EX/6180/6480BT/6980
