Kenwood DNX5280BT Service Manual

PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
118
DNX4280BT/5180/5280BT/5380/5380M
/5380BT/5580BT/6040EX/6180/6480BT/6980
K: DNX6980 K1: DNX6180 K2: DNX6040EX K3: DNX5180 (North America)
E1: DNX5280BT E2: DNX4280BT (Europe) Q1: DNX5580BT (Russian)
R1: DNX6480BT (Latin America) X1: DNX5380BT (Australia)
C1: DNX5380 (China) M1: DNX5380 M2: DNX5380M (Other Areas)
R803 RK73HB1J100J CHIP R 10 J 1/16W
R804 RK73HB1J473J CHIP R 47K J 1/16W
R806-808 RK73GB2A000J CHIP R 0.0 J 1/10W
R811 RK73GB2A152J CHIP R 1.5K J 1/10W
R812 RK73FB2B151J CHIP R 150 J 1/8W
IC103
✽
- MICROPROCESSOR IC
IC402,403
✽
- DRAM IC
IC500,501
✽
- DRAM IC
IC704 THS8136IPHPR MOS-IC
IC705 TC7SG86FU-F MOS-IC
IC706
✽
W05-1700-00 ROM IC
IC707 TC7SG04FU-F MOS-IC
IC708 XC6215B182NR ANALOGUE IC
IC714
✽
ML86V8202T03 MOS-IC
1 1A A10-5523-11+ CHASSIS
2 2B A10-5543-01 CHASSIS
3 1A A10-5535-01 CHASSIS
4 3A A10-5534-12 CHASSIS
7 1B D10-7080-02 ARM
8 1B D10-7081-02 ARM
9 1B D10-7082-02 LEVER
10 1B D10-7083-02 LEVER
12 2B D10-7084-02+ SLIDER
13 2A D10-7100-02 ARM
14 2B D10-7086-03+ ARM
15 2B D10-7087-02 ARM
25 2B D10-7092-04+ SLIDER ASSY
27 2A D10-7091-04 LEVER
28 2B D12-0640-02+ CAM
31 2B D13-3029-04 GEAR
32 2B D13-3030-04 GEAR
33 2B D13-3031-04 GEAR
34 2B D13-3032-04 GEAR
35 2B D13-3033-04 GEAR
36 2B D13-3034-04 GEAR
40 2A D13-3038-04 GEAR
41 2A D13-3039-04 GEAR
42 2A D13-3040-04 GEAR
43 1B
✽
D14-1034-04 ROLLER
53 1B D21-2487-24+ SHAFT
54 2A D39-0275-05 DAMPER
55 2A D39-0276-05 DAMPER
60 3A F09-3037-03 SHEET
65 2B G01-4734-04 EXTENSION SPRING
66 1B G01-4735-14 EXTENSION SPRING
67 2A G01-3300-14+ TORSION COIL SPRING
68 2B G01-4737-14 EXTENSION SPRING
69 1B G01-4602-14+ EXTENSION SPRING
70 1B G01-4740-04 TORSION COIL SPRING
74 2B G01-4609-24+ TORSION COIL SPRING
75 1B G02-1904-03+ FLAT SPRING
79 2A J22-0898-01 MOUNTING HARDWARE
80 3B J22-0891-11+ MOUNTING HARDWARE
A 1A N09-6815-05 MACHINE SCREW (M1.7X2.0)
B 3B N09-6408-15 TAPTITE SCREW (1.7X4.0 PT)
C 1B N09-6426-15
MACHINE SCREW (LOAD ARM SCREW
D 3A N09-6104-05 MACHINE SCREW (2X10 ST)
93 2A T99-0471-05 MAGNET
96 1B X94-2080-00 ROLLER ASSY
98 2A X94-2120-00
TRAVERSE ASSY (PICKUP,SPINDLE)
VM1 2A X94-2070-00 MOTOR ASSY (LOADING)
DVD MECHANISM ASSY (X92-6640-00) (DVS-8710W)
DIGITAL I/O UNIT (X88-2080-xx)
The IC103,402, 403, 500 and IC501 in the DIGITAL I/O UNIT (X88-2080-xx)
are not replaceable components. When these ICs are defective, replace the
whole DIGITAL I/O UNIT (X88-2080-xx).

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
