Kenwood DNX5280BT User Manual

2222
Return to the Top page
DVD, VCD
DVD/VCD Basic Operation
Most functions can be controlled from the source control screen and playback screen.
NOTE
• Set the remote controller mode switch to DVD mode before starting operation, see Switching the operation
mode (P.87).
• The screen shot below is for DVD. It may be different from the one for VCD.
2
3
4
1
5
Video screenControl screen
6 6
7
8
1 Information display
Displays the following information.
• Title #, Chap #: DVD title and chapter number display
• Track #/Scene #: VCD track or scene number display
*Scene # is displayed only when PBC is on.
• 3, ¡, ¢, 7, etc.: Current play mode display
The meanings of each icon are as follows; 3 (play), ¡ (fast forward), 1 (fast backward),
¢ (search up), 4 (search down), 7 (stop), 7R (resume stop), 8 (pause),
(slow playback),
(slow reverse playback).
Touch this area to display the disc lable name.
2 Multi function key
Touch to switch the multi function menu. For details on the menu, see Multi function menu (P.24).
3 Multi function menu
Various functions can be performed by using keys in this area. For details on the keys, see Multi
function menu (P.24).
4 Control switching key
Unavailable in DVD/VCD source.
DVD/Video CD (VCD) Operation

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
