Kenwood DNX5280BT User Manual

13
Return to the Top page
Basic Operations
How To Play Media
Music CD and disc media
Press the <0> button for 1 second.
The panel opens.
Insert the disc into the slot.
The panel closes automatically.
The unit loads the disc and playback
starts.
 To eject the disc:
Press the <0> button when the panel is
closed.
Insert the disc into the slot.
The unit loads the disc and playback
starts.
 To eject the disc:
Press the <0> button.
USB device
Connect the USB device with the
USB cable.
The unit reads the device and playback
starts.
 To disconnect the device:
Touch [0] for 1 second on the screen and
disconnect the device from the cable.
iPod
Connect the iPod with the iPod
cable.
The unit reads the iPod and playback
starts.
 To disconnect the device:
Touch [ ] on the screen and then touch
[0] for 1 second. Disconnect the iPod
from the cable.
1
2
1
1
1

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
