DNX SERIES/ DDX SERIES
Installation Procedure
1
..........1
2
..........1
3
..........1
4
..........1
5
..........2
6
..........1
7
..........1
8
..........6
9
..........6
0
..........1
!
DNX9960 only
..........1
@
DNX9960 only
..........1
#
..........1
$
DNX9960 only
..........1
%
DNX9960 only
..........1
Accessories
1. To prevent a short circuit, remove the key
from the ignition and disconnect the -
battery.
2. Make the proper input and output wire
connections for each unit.
3. Connect the speaker wires of the wiring
harness.
4. Connect the wiring harness wires in the
following order: ground, battery, ignition.
5. Connect the wiring harness connector to
the unit.
6. Install the unit in your car.
7. Reconnect the - battery.
8. Press the reset button.
9. Perform the Initial Setup. (Refer to the
Instruction Manual.)
2WARNING
• If you connect the ignition wire (red) and the
battery wire (yellow) to the car chassis (ground),
you may cause a short circuit, that in turn may
start a fire. Always connect those wires to the
power source running through the fuse box.
• Do not cut out the fuse from the ignition wire
(red) and the battery wire (yellow). The power
supply must be connected to the wires via the
fuse.
Acquiring GPS Signals
The first time you turn on DNX9960, you
must wait while the system acquires satellite
signals for the first time. This process could
take up to several minutes. Make sure your
vehicle is outdoors in an open area away from
tall buildings and trees for fastest acquisition.
After the system acquires satellites for the
first time, it will acquire satellites quickly each
time thereafter.
About the Front Panel
When removing the product from the
box or installing it, the front panel may be
positioned at the angle shown in (Fig. 1). This
is due to the characteristics of mechanism
the product is equipped with.
When the product is first powered on works
