Kenwood NXR-800 Service Manual Supplement

NXR-800
36
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
TX UNIT (X56-3120-XX)
R879 RK73GB2A104J CHIP R 100K J 1/10W
R881 RK73GB2A000J CHIP R 0.0 J 1/10W K
R882 RK73GB2A000J CHIP R 0.0 J 1/10W K2
R887-889 RK73GB2A102J CHIP R 1.0K J 1/10W
R891 RK73GB2A102J CHIP R 1.0K J 1/10W
R920-932 RK73GB2A000J CHIP R 0.0 J 1/10W
R933 RK73GB2A821J CHIP R 820 J 1/10W
R934,935 RK73GB2A000J CHIP R 0.0 J 1/10W
R936,937 RK73GB2A122J CHIP R 1.2K J 1/10W
R938,939 RK73GB2A821J CHIP R 820 J 1/10W
R940 RK73GB2A122J CHIP R 1.2K J 1/10W
R941 RK73GB2A821J CHIP R 820 J 1/10W
R942 RK73GB2A000J CHIP R 0.0 J 1/10W
R943 RK73GH2A224D CHIP R 220K D 1/10W
R944,945 RK73GB2A102J CHIP R 1.0K J 1/10W
R946 RK73GB2A103J CHIP R 10K J 1/10W
R947 RK73GB2A000J CHIP R 0.0 J 1/10W
R948,949 RK73GH2A104D CHIP R 100K D 1/10W
R950 RK73GH2A822D CHIP R 8.2K D 1/10W
R951 RK73GB2A122J CHIP R 1.2K J 1/10W
R960-965 RK73GB2A000J CHIP R 0.0 J 1/10W
R966,967 RK73GB2A681J CHIP R 680 J 1/10W
VR401,402 R32-0754-05 SEMI FIXED VARIABLE RESISTOR(10K)
S920-925 S70-0502-05 TACT SWITCH
D101,102 1SV283F VARIABLE CAPACITANCE DIODE
D106 1SV278F VARIABLE CAPACITANCE DIODE
D107,108 1SV283F VARIABLE CAPACITANCE DIODE
D112 1SV278F VARIABLE CAPACITANCE DIODE
D201 HSM88AS-E DIODE
D401-403 HSM88AS-E DIODE
D404,405 JDP4P02U DIODE
D406,407 HSC119 DIODE
D408 HSM88AS-E DIODE
D409 CSA70-401L SURGE ABSORBER
D601,602 JDP4P02U DIODE
D603-606 UDZS3.0B ZENER DIODE
D933,934 HSM88AS-E DIODE
D935,936 1SS355 DIODE
D960,961 PSA0511EWA-FG1 LED
IC101 LMX2352TMX/NP ANALOGUE IC
IC102 LMC7101BIM5 MOS-IC
IC104 NJM2386ADL3-09 ANALOGUE IC
IC201 NJM2904E-ZB ANALOGUE IC
IC202 AD9835BRUZ MOS-IC
IC301 NJM2732V BI-POLAR IC
IC302 NJU6368PF1 MOS-IC
IC303 ADF4001BRUZ MOS-IC
IC304 M62364FP-F MOS-IC
IC305 NJM2732V BI-POLAR IC
IC306 LMC7101BIM5 MOS-IC
IC307 NJU6368PF1 MOS-IC
IC308 NJM2732V BI-POLAR IC
IC401 LMC7101BIM5 MOS-IC
IC404 ADF4001BRUZ MOS-IC
IC405,406
✽
TC75S59F-F MOS-IC
IC407 NJU6368PF1 MOS-IC
IC408,409 TA75S01F-F MOS-IC
IC601 AD9835BRUZ MOS-IC
IC602 NJU6368PF1 MOS-IC
IC603 XC6204B332M MOS-IC
IC701 BH2220FVM ANALOGUE IC
IC702 S24CS02AFJTBG ROM IC
IC703 BU4094BCFV MOS-IC
IC704 NJM78M08DL1AZB ANALOGUE IC
IC705,706 NJM78M05DL1AZB ANALOGUE IC
IC801 AD1582 ANALOGUE IC
IC802 AD5312BRM MOS-IC
IC803 AD7908BRU MOS-IC
IC804 LM50BIM3/NOPB MOS-IC
IC805,806 TC7SET126FU-F MOS-IC
IC807 NJM78M05DL1AZB ANALOGUE IC
IC808,809 1B NJM7808FA-ZB BI-POLAR IC
IC920-922 TC7SET126FU-F MOS-IC
IC923-925 BU4094BCFV MOS-IC
IC926 NJM2732V BI-POLAR IC
IC960-963 BU4094BCFV MOS-IC
Q101 SSM3K15TE(F) FET
Q102,103 2SK508NV(K52) FET
Q104 2SC3356-A(R24) TRANSISTOR
Q105 2SC4116(BL)F TRANSISTOR
Q106 2SC3356-A(R24) TRANSISTOR
Q107,108 2SC4116(BL)F TRANSISTOR
Q109 2SA1832F TRANSISTOR
Q110 SSM3K15TE(F) FET
Q201 2SC3356-A(R24) TRANSISTOR
Q202 2SC5337 TRANSISTOR
Q203 RD01MUS1-T113 FET
Q204 SSM3K15TE(F) FET
Q205 SSM3J01F FET
Q206 SSM3K15TE(F) FET
Q210 SSM3K15TE(F) FET
Q211-213 2SC4617(R) TRANSISTOR
Q301,302 SSM3K15TE(F) FET
Q303 2SA1832F TRANSISTOR
Q304,305 2SC4617(R) TRANSISTOR
Q307 2SC4617(R) TRANSISTOR
Q401,402 2SC4617(R) TRANSISTOR
Q405 SSM3K15TE(F) FET
Q407-409 SSM3K15TE(F) FET
Q410 2SA1832F TRANSISTOR
Q412 2SC4617(R) TRANSISTOR
Q413,414 SSM3K15TE(F) FET
Q415-419 2SC4617(R) TRANSISTOR
Q420 3SK317-E FET
Q421 SSM6L05FU-F FET
Q422 RD01MUS1-T113 FET
Q423 SSM6L05FU-F FET
Q424 SSM3K15TE(F) FET
Q425 RD01MUS1-T113 FET
Q426 SSM3J01F FET
Q428,429 SSM3K15TE(F) FET
Q430,431 3SK317-E FET
Q601 SSM3J01F FET
Q602 SSM3K15TE(F) FET
Q603 2SC4617(R) TRANSISTOR
Q604 SSM3K15TE(F) FET
Q605 SSM3J01F FET
Q606 2SC4617(R) TRANSISTOR
Q607-609 SSM3K15TE(F) FET
If a part reference number is listed in a shaded box, that part does not come with the PCB.
