TK-3170
27
PARTS LIST
✽ New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L : Scandinavia K : USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Europe
Y : AAFES (Europe) X : Australia M :Other Areas
11A✽ A02-3891-13 PLASTIC CABINET ASSY
33A✽ A10-4088-01 CHASSIS
53AB01-0694-03 ESCUTCHEON
62D✽ B09-0686-03 CAP ACCESSORY
72B✽ B11-1826-03 ILLUMINATION GUIDE
82A✽ B11-1827-04 ILLUMINATION GUIDE
92B✽ B11-1828-04 FILTER
10 2B ✽ B38-0901-05 LCD
13 1B ✽ B43-1178-04 BADGE
17 3C ✽ B62-1812-00 INSTRUCTION MANUAL
20 2A E04-0436-05 RF COAXIAL RECEPTACLE (SMA)
21 2A E23-1188-04 TERMINAL
22 3A E23-1189-14 TERMINAL
23 2B ✽ E29-1204-04 INTER CONNECTOR (LCD)
24 2B ✽ E29-1211-04 INTER CONNECTOR (4-KEY)
25 2A ✽ E37-1142-05 FLAT CABLE
26 3A ✽ E72-0421-03 TERMINAL BLOCK
28 3A ✽ F07-1890-04 COVER
30 1B G10-1304-04 FIBROUS SHEET (CABINET ASSY)
- G10-1333-04 FIBROUS SHEET (CABINET ASSY)
31 3A ✽ G11-4315-04 SHEET
32 2A ✽ G11-4316-04 SHEET
33 2B ✽ G11-4335-14 SHEET
34 1B ✽ G11-4351-04 SHEET
35 2A G13-1885-04 CUSHION
36 3A G13-2001-04 CUSHION
38 2A G53-1603-04 PACKING
39 2B ✽ G53-1650-12 PACKING
41 1B ✽ G53-1652-11 PACKING
42 2B ✽ G53-1653-03 PACKING
43 3A ✽ G53-1654-04 PACKING
44 3A ✽ G53-1655-04 PACKING
46 2C H12-3150-02 PACKING FIXTURE
47 2D H25-0029-04 PROTECTION BAG (60/110/0.07)
48 1D ✽ H52-2067-02 ITEM CARTON CASE
50 2B ✽ J19-5481-03 HOLDER
51 2D ✽ J19-5483-23 HOLDER ACCESSORY
52 1B ✽ J21-8488-03 MOUNTING HARDWARE
53 2C ✽ J29-0701-15 HOOK ACCESSORY
54 3A ✽ J82-0106-05 FPC
55 2A ✽ J99-0399-04 DOUBLE-SIDED TAPE (4x7mm)
56 1B K29-9278-13 KNOB (VOLUME)
57 1B ✽ K29-9339-03 KNOB (PTT)
58 1B ✽ K29-9340-13 KNOB (SELECTOR)
59 1B ✽ K29-9341-03 KEY TOP (SIDE)
A 2A,3A ✽ N09-2438-05 BINDING HEAD SCREW
B2AN14-0583-04 CIRCULAR NUT
C3BN14-0805-04 CIRCULAR NUT
D3A✽ N30-2610-48 PAN HEAD MACHINE SCREW
E3AN30-3006-43 PAN HEAD MACHINE SCREW
F3A✽ N79-2030-48 PAN HEAD TAPTITE SCREW
G 2A,2B ✽ N83-2005-48 PAN HEAD TAPTITE SCREW
61 3A ✽ R31-0655-05 VARIABLE RESISTOR
63 1B T07-0369-05 SPEAKER
64 2B ✽ T91-0650-05 MIC ELEMENT
66 2A W02-3684-05 SELECTOR
D2 B30-2278-05 LED (RED/YELLOW)
D5 B30-2210-05 LED (TLY)
D7 B30-2210-05 LED (TLY)
D8,9 B30-2050-05 LED
D12,13 B30-2050-05 LED
C2 CK73HB1H471K CHIP C 470PF K
C3 CK73FB1A475K CHIP C 4.7UF K
C4 CK73GB1E105K CHIP C 1.0UF K
C5,6 CK73HB1H471K CHIP C 470PF K
C7 CK73HB1A104K CHIP C 0.10UF K
C9 CK73GB1E105K CHIP C 1.0UF K
C11 CK73FB1A225K CHIP C 2.2UF K
C13 CK73HB1H471K CHIP C 470PF K
C14,15 CK73HB1E472K CHIP C 4700PF K
C16,17 CK73HB1H471K CHIP C 470PF K
C18 CK73HB1A104K CHIP C 0.10UF K
C19 CK73HB1H471K CHIP C 470PF K
C20 CK73HB1E472K CHIP C 4700PF K
C21 CK73HB1H471K CHIP C 470PF K
C22 CK73HB1E472K CHIP C 4700PF K
C23,24 CK73GB1E105K CHIP C 1.0UF K
C25 CK73HB1E472K CHIP C 4700PF K
C26 CK73HB1H471K CHIP C 470PF K
C27 C92-0712-05 CHIP-TAN 22UF 6.3WV
C28-31 CK73HB1H471K CHIP C 470PF K
C32,33 CK73HB1A104K CHIP C 0.10UF K
C34 CK73HB1H471K CHIP C 470PF K
C35 CK73HB1A104K CHIP C 0.10UF K
C38,39 CK73HB1A473K CHIP C 0.047UF K
C40 CK73HB1H471K CHIP C 470PF K
C42 CK73HB1H681K CHIP C 680PF K
C43,44 CK73HB1C103K CHIP C 0.010UF K
C45 C92-0712-05 CHIP-TAN 22UF 6.3WV
C46 CK73HB1H471K CHIP C 470PF K
C47 CK73GB1E105K CHIP C 1.0UF K
C48-51 CK73HB1H471K CHIP C 470PF K
C52 CK73HB1A104K CHIP C 0.10UF K
C53 CK73HB1H471K CHIP C 470PF K
C55 CK73GB1E105K CHIP C 1.0UF K
C56 CK73HB1A104K CHIP C 0.10UF K
TK-3170 (Y50-586X-XX)
TX-RX UNIT (X57-701X-XX)
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TK-3170
TX-RX UNIT (X57-701X-XX) 2-71 : E 0-71 : X2
