Kenwood TS-2000 Service Manual Supplement

TS-2000/X,TS-B2000
PARTS LIST
11
K : TS-2000 (K) KB : TS-B2000 (K) KX : TS-2000X (K) E : TS-2000 (E)
EB : TS-B2000 (E) E2 : TS-2000 (E2) E2B : TS-B2000 (E2) EX : TS-2000X (E)
Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description
New Desti-
parts nation
New Desti-
parts nation
FILTER UNIT (X51-315X-XX)
C407 C93-0571-05 CHIP C 82PF J E2B,EX
C408 CK73FB1H103K CHIP C 0.010UF K
C411 C93-0560-05 CHIP C 10PF D K,KB,KX
C451,452 C93-0562-05 CHIP C 15PF J
C453 C93-0572-05 CHIP C 100PF J
C454 C93-0571-05 CHIP C 82PF J
C455 C93-0566-05 CHIP C 33PF J
C456 C93-0571-05 CHIP C 82PF J
C457 CK73FB1H103K CHIP C 0.010UF K
C458 C93-0552-05 CHIP C 2.0PF C
C501 C93-0571-05 CHIP C 82PF J
C502 C93-0569-05 CHIP C 56PF J
C503 C93-0571-05 CHIP C 82PF J
C504 C93-0572-05 CHIP C 100PF J
C505 C93-0562-05 CHIP C 15PF J
C506 C93-0570-05 CHIP C 68PF J
C507 CK73FB1H103K CHIP C 0.010UF K
C508 C93-0555-05 CHIP C 5.0PF C
C509 C93-0552-05 CHIP C 2.0PF C
C551 C93-0558-05 CHIP C 8.0PF D
C553 C93-0568-05 CHIP C 47PF J
C554 C93-0559-05 CHIP C 9.0PF D
C555 C93-0569-05 CHIP C 56PF J
C557 C93-0562-05 CHIP C 15PF J
C558 C93-0563-05 CHIP C 18PF J
C559,560 CK73FB1H103K CHIP C 0.010UF K
C561 C93-0558-05 CHIP C 8.0PF D
C562 C93-0554-05 CHIP C 4.0PF C
C563 C93-0553-05 CHIP C 3.0PF C
C601 C93-0555-05 CHIP C 5.0PF C
TC1 C05-0031-15 CERAMIC TRIMMER CAP (10PF)
CN2,3 E23-0996-05 TEST TERMINAL
CN4 E04-0154-05 PIN SOCKET
CN5-8 E23-0996-05 TEST TERMINAL
CN9 E40-3256-05 PIN ASSY
CN10 E40-3254-05 PIN ASSY
CN12,13 E04-0154-05 PIN SOCKET
CN20 E04-0154-05 PIN SOCKET
CN21 E04-0190-05 PIN SOCKET
- L92-0104-05 TROIDAL CORE
- L92-0107-05 TROIDAL CORE
- L92-0108-05 TROIDAL CORE
L2,3 L34-1232-15 AIR-CORE COIL
L4 L40-1095-34 SMALL FIXED INDUCTOR (1UH)
L5 L34-1088-05 AIR-CORE COIL
L6 L40-1021-12 SMALL FIXED INDUCTOR
L7 L39-0480-15 TOROIDAL COIL
L8 L40-1021-12 SMALL FIXED INDUCTOR
L9 L39-1442-05 TOROIDAL COIL
L10 L39-1443-05 TOROIDAL COIL
L11,12 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L13 L40-1885-48 SMALL FIXED INDUCTOR (180NH)
L14,15 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L16 L40-2775-34 SMALL FIXED INDUCTOR (27NH) E,EB,E2
L16 L40-2775-34 SMALL FIXED INDUCTOR (27NH) E2B,EX
L201 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L202 L39-1259-05 TOROIDAL COIL
L203 L39-1260-05 TOROIDAL COIL
L251 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L252 L39-1405-05 TOROIDAL COIL
L253 L39-1225-05 TOROIDAL COIL
L301 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L302,303 L39-1457-05 TOROIDAL COIL
L351 L40-4705-34 SMALL FIXED INDUCTOR (47UH) E,EB,E2
L351 L40-4705-34 SMALL FIXED INDUCTOR (47UH) E2B,EX
L352,353 L39-1221-05 TOROIDAL COIL E,EB,E2
L352,353 L39-1221-05 TOROIDAL COIL E2B,EX
L401 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L402-404 L39-1456-05 TOROIDAL COIL
L451 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L452,453 L34-1279-05 AIR-CORE COIL
L501 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L502 L34-4661-05 AIR-CORE COIL
L503 L34-1282-05 AIR-CORE COIL
L551 L40-4705-34 SMALL FIXED INDUCTOR (47UH)
L552 L34-4662-05 AIR-CORE COIL
L553 L34-4491-05 AIR-CORE COIL
L554 L34-1359-05 AIR-CORE COIL
R2,3 R92-1205-05 CHIP R 120 J 1/4W
R5 RK73FB2A100J CHIP R 10 J 1/10W
R6 R92-0686-05 CHIP R 33 J 1/2W
R7 R92-1212-05 CHIP R 27 J 1/2W
R8 R92-1316-05 CHIP R 39 J 1W
R9,10 RK73FB2A101J CHIP R 100 J 1/10W
R11-14 RK73FB2A104J CHIP R 100K J 1/10W
R15,16 RK73FB2A102J CHIP R 1.0K J 1/10W
R17,18 RK73FB2A101J CHIP R 100 J 1/10W
R19,20 RK73FB2A104J CHIP R 100K J 1/10W
R21,22 RK73FB2A103J CHIP R 10K J 1/10W
R23,24 RK73FB2A152J CHIP R 1.5K J 1/10W
R25,26 RK73FB2A102J CHIP R 1.0K J 1/10W
R27,28 RK73FB2A332J CHIP R 3.3K J 1/10W
R29,30 RK73FB2A151J CHIP R 150 J 1/10W
R31,32 RK73FB2A122J CHIP R 1.2K J 1/10W
R33 RK73FB2A103J CHIP R 10K J 1/10W
R34 RK73FB2A332J CHIP R 3.3K J 1/10W
R35 RK73FB2A103J CHIP R 10K J 1/10W
R36 RK73FB2A332J CHIP R 3.3K J 1/10W
R37,38 RK73FB2A103J CHIP R 10K J 1/10W
R39 RK73FB2A101J CHIP R 100 J 1/10W
R40 RK73FB2A333J CHIP R 33K J 1/10W
R41 R92-0670-05 CHIP R 0 OHM K,KB,KX
VR1 R12-6730-05 TRIMMING POT. (220)
VR2 R12-6742-05 TRIMMING POT. (22K)
K1 S51-1429-05 RELAY
K2 S76-0430-05 RELAY
K3,4 S76-0424-05 RELAY
K201,202 S76-0423-05 RELAY
K251,252 S76-0423-05 RELAY
K301,302 S76-0423-05 RELAY
K351,352 S76-0423-05 RELAY E,EB,E2
K351,352 S76-0423-05 RELAY E2B,EX
K401,402 S76-0423-05 RELAY
K451,452 S76-0423-05 RELAY
K501,502 S51-1420-05 RELAY
K551,552 S51-1420-05 RELAY
D2 1SS355 DIODE

Kenwood TS-2000 Specifications

General

Antenna Impedance	50 ohms
Supply Voltage	13.8V DC ±15%
Current Drain TX	20.5A
Receiver Type	Triple Conversion Superheterodyne
Modes	SSB, CW, AM, FM, FSK
Type	Base Station
Frequency Range TX	0.1-60 MHz (HF), 144-148 MHz (VHF), 430-450 MHz (UHF)
Image Rejection	More than 70 dB
Selectivity	2.4 kHz (SSB), 500 Hz (CW), 15 kHz (FM)
Antenna Connector	SO-239
Frequency Range	HF/6m/2m/70cm
