Kenwood TS-2000 Service Manual Supplement

TS-2000/X,TS-B2000
PARTS LIST
16
K : TS-2000 (K) KB : TS-B2000 (K) KX : TS-2000X (K) E : TS-2000 (E)
EB : TS-B2000 (E) E2 : TS-2000 (E2) E2B : TS-B2000 (E2) EX : TS-2000X (E)
Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description
New Desti-
parts nation
New Desti-
parts nation
IC517 NJM2904V IC (ANALOG AGC BUFFER)
IC518 AK4524 IC (CODEC(24BIT))
IC519 TC7W74FU IC (FOR CODEC CLOCK DIVISION)
IC520 TC7WU04FU IC (FOR CODEC CLOCD DIVISION)
IC521 TC74VHC4040FT IC (FOR CODEC CLOCK DIVISION)
IC522,523 AK4518 IC (DODEC(16BIT))
IC524-529 NJM2100V
IC (BUFFER FOR ANALOG SIGNAL INPUT/OUTPUT)
IC530 BU2099FV IC (SERIAL/PARALLEL)
IC531-534 BU4066BCFV IC (ANALOG SWITCH)
IC535 NJM2100V
IC (BUFFER FOR ANALOG SIGNAL INPUT/OUTPUT)
Q1 DTC143EUA DIGITAL TRANSISTOR
Q2 DTA143EUA DIGITAL TRANSISTOR
Q3 DTC143EUA DIGITAL TRANSISTOR
Q4 DTA143EUA DIGITAL TRANSISTOR
Q5 DTC143EUA DIGITAL TRANSISTOR
Q9,10 DTC114EUA DIGITAL TRANSISTOR
Q13,14 2SC4617(R) TRANSISTOR
Q15 2SA1774(R) TRANSISTOR
Q16 2SC4617(R) TRANSISTOR
Q17 DTC143TUA DIGITAL TRANSISTOR
Q18 DTA143EUA DIGITAL TRANSISTOR
Q19 2SA1774(R) TRANSISTOR
Q20 DTA143EUA DIGITAL TRANSISTOR
Q501 DTC144EUA DIGITAL TRANSISTOR
201 1E B11-1245-02 ILLUMINATION GUIDE
202 1E B11-1246-13 FILTER
203 2E B11-1257-03 FILTER
204 1E B30-2221-05 LAMP (5.5V/125MA/)
205 2E B38-0837-05 LCD
D1,2 B30-2217-05 LED (Y)
D3-9 B30-2167-05 LED (GR)
C1,2 CK73GB1H103K CHIP C 0.010UF K
C3-9 CK73FB1E104K CHIP C 0.10UF K
C10 CK73GB1H103K CHIP C 0.010UF K
C11 CK73FB1E104K CHIP C 0.10UF K
C12 C92-0041-05 CHIP-ELE 10UF 10WV
C13 CK73GB1H103K CHIP C 0.010UF K
C15-23 CK73GB1H102K CHIP C 1000PF K
C25-32 CK73GB1H102K CHIP C 1000PF K
C33 C92-0038-05 CHIP-ELE 22UF 16WV
C34 C92-0041-05 CHIP-ELE 10UF 10WV
C35 CK73FB1E223K CHIP C 0.022UF K
C36 CK73GB1H103K CHIP C 0.010UF K
207 2E E29-1186-04 INTER CONNECTOR
208 2E E29-1187-04 INTER CONNECTOR
CN1 E40-5736-05 FLAT CABLE CONNECTOR
211 2E G11-4043-04 SHEET
212 2E J21-8397-03 HARDWARE FIXTURE
L3,4 L40-1095-48 SMALL FIXED INDUCTOR (1UH)
R1,2 RK73GB1J154J CHIP R 150K J
R3 RK73FB2A105J CHIP R 1.0M J
R4 RK73FB2A684J CHIP R 680K J 1/10W
R5 RK73FB2A100J CHIP R 10 J 1/10W
R6-21 RK73GB1J101J CHIP R 100 J 1/16W
R23 RK73GB1J101J CHIP R 100 J 1/16W
R27 RK73FB2A681J CHIP R 680 J 1/10W
R29 RK73FB2A681J CHIP R 680 J 1/10W
R31 RK73FB2A560J CHIP R 56 J 1/10W
R32 RK73FB2A221J CHIP R 220 J 1/10W
R35 RK73FB2A222J CHIP R 2.2K J 1/10W
R36 RK73FB2A102J CHIP R 1.0K J 1/10W
R37 RK73FB2A392J CHIP R 3.9K J 1/10W
R38 RK73FB2A682J CHIP R 6.8K J 1/10W
R39 RK73FB2A152J CHIP R 1.5K J 1/10W
R40 RK73FB2A272J CHIP R 2.7K J 1/10W
R41-43 R92-1211-05 CHIP R 5.6 J 1/2W
VR1 R32-0676-05 SEMI FIXED VARIABLE RESISTOR
S1-12 S70-0475-05 TACT SWITCH
IC1,2 NJU6433F IC (LCD DRIVER)
IC3 SED1526F0A IC (LCD DRIVER)
IC4 BU2099FV IC (SERIAL/PARALLEL)
Q1 2SA1641(S,T) TRANSISTOR
Q2 2SC2712(Y) TRANSISTOR
Q3 2SA1162(Y) TRANSISTOR
D86 B30-2001-05 LED (RED)
D105 B30-2001-05 LED (RED)
D801 B30-2138-05 LED (SR) K,KX,E
D801 B30-2138-05 LED (SR) E2,EX
D802 B30-2139-05 LED (G) K,KX,E
D802 B30-2139-05 LED (G) E2,EX
D803 B30-2138-05 LED (SR) K,KX,E
D803 B30-2138-05 LED (SR) E2,EX
D804 B30-2139-05 LED (G) K,KX,E
D804 B30-2139-05 LED (G) E2,EX
D810-824 B30-2167-05 LED (GR) K,KX,E
D810-824 B30-2167-05 LED (GR) E2,EX
D825 B30-2146-05 LED (OR) K,KX,E
D825 B30-2146-05 LED (OR) E2,EX
D826-834 B30-2167-05 LED (GR) K,KX,E
D826-834 B30-2167-05 LED (GR) E2,EX
D953,954 B30-2217-05 LED (Y) K,KX,E
D953,954 B30-2217-05 LED (Y) E2,EX
D955 B30-2167-05 LED (GR) K,KX,E
D955 B30-2167-05 LED (GR) E2,EX
D956 B30-2218-05 LED (OR) K,KX,E
D956 B30-2218-05 LED (OR) E2,EX
D957 B30-2140-05 LED (Y) K,KX,E
D957 B30-2140-05 LED (Y) E2,EX
D958 B30-2168-05 LED (RED) KB,EB,E2B
C1,2 CK73GB1H103K CHIP C 0.010UF K
C3 CC73GCH1H470J CHIP C 47PF J
C4 CC73GCH1H070D CHIP C 7.0PF D
C5 CC73GCH1H470J CHIP C 47PF J
C6 CK73EB1H104K CHIP C 0.10UF K
C7,8 CK73GB1H103K CHIP C 0.010UF K
C9 CK73GB1H222K CHIP C 2200PF K
C10 CK73FB1E104K CHIP C 0.10UF K
C11 CK73FB1C105K CHIP C 1.0UF K
DISPLAY UNIT (X54-3320-00) : K,KX,E,E2,EX
TX-RX 1 UNIT (X57-605X-XX)
0-11 : K,KX 0-12 : KB 2-71 : E,E2,EX 2-72 : EB,E2B
CONTROL UNIT (X53-391X-XX)
DISPLAY UNIT (X54-3320-00) : K,KX,E,E2,EX
TX-RX 1 UNIT (X57-605X-XX)

Kenwood TS-2000 Specifications

General

Antenna Impedance	50 ohms
Supply Voltage	13.8V DC ±15%
Current Drain TX	20.5A
Receiver Type	Triple Conversion Superheterodyne
Modes	SSB, CW, AM, FM, FSK
Type	Base Station
Frequency Range TX	0.1-60 MHz (HF), 144-148 MHz (VHF), 430-450 MHz (UHF)
Image Rejection	More than 70 dB
Selectivity	2.4 kHz (SSB), 500 Hz (CW), 15 kHz (FM)
Antenna Connector	SO-239
Frequency Range	HF/6m/2m/70cm
