Kenwood TS-2000 Service Manual Supplement

TS-2000/X,TS-B2000
PARTS LIST
6
K : TS-2000 (K) KB : TS-B2000 (K) KX : TS-2000X (K) E : TS-2000 (E)
EB : TS-B2000 (E) E2 : TS-2000 (E2) E2B : TS-B2000 (E2) EX : TS-2000X (E)
Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description
New Desti-
parts nation
New Desti-
parts nation
TS-2000/X, TS-B2000
FINAL UNIT (X45-360X-XX)
N 3E N90-3008-46 TP HEAD MACHINE SCREW K,KX,E
N 3E N90-3008-46 TP HEAD MACHINE SCREW E2,EX
135 1I N99-2024-05 SCREW SET ACCESSORY
- S50-1406-05 TACT SWITCH (MICROPHONE)
139 3B T07-0252-35 SPEAKER
140 1I T91-0352-15 MICROPHONE ACCESSORY
141 1J ✽ T93-0123-25 CD-ROM ACCESSORY KB,EB,E2B
142 2F W02-1836-05 ENCODER (MAIN) K,KX,E
142 2F W02-1836-05 ENCODER (MAIN) E2,EX
143 1F W02-3619-05 ENCODER (RIT/SUB) K,KX,E
143 1F W02-3619-05 ENCODER (RIT/SUB) E2,EX
- W09-0873-05 LITHIUM CELL (X57-605A)
146 2E 212-2017-05 HEAT-PROOF TUBE (VOX,FUNC) K,KX,E
146 2E 212-2017-05 HEAT-PROOF TUBE (VOX,FUNC) E2,EX
C1 CK73FB1E104K CHIP C 0.10UF K
C2 CK73FB1H103K CHIP C 0.010UF K
C3 CK73FB1E104K CHIP C 0.10UF K
C4 CK73FB1H103K CHIP C 0.010UF K
C5 CK73FB1H102K CHIP C 1000PF K
C6 CK73FB1E104K CHIP C 0.10UF K
C7 CK73FB1C105K CHIP C 1.0UF K
C8,9 CK73FB1E104K CHIP C 0.10UF K
C10 CK73FB1C105K CHIP C 1.0UF K
C11 CK73FB1H102K CHIP C 1000PF K
C12 CE04EW1E100M ELECTRO 10UF 25WV
C13 CK73FB1E104K CHIP C 0.10UF K
C14 CK73FB1H102K CHIP C 1000PF K
C15 CK73FB1E104K CHIP C 0.10UF K
C16 CC73FCH1H100D CHIP C 10PF D
C17 CK73FB1E104K CHIP C 0.10UF K
C20 CC73FCH1H331J CHIP C 330PF J
C21 CK73FB1E104K CHIP C 0.10UF K
C22 CK73FB1H102K CHIP C 1000PF K
C24 CK73FB1E104K CHIP C 0.10UF K
C25 CK73FB1C105K CHIP C 1.0UF K
C26 CC73FCH1H390J CHIP C 39PF J
C27 CC73FCH1H470J CHIP C 47PF J
C29,30 CK73EB1H104K CHIP C 0.10UF K
C31 C93-0569-05 CHIP C 56PF J
C32 CK73FB1H102K CHIP C 1000PF K
C33 CE04EW1E100M ELECTRO 10UF 25WV
C34 CE04EW1E470M ELECTRO 47UF 25WV
C35 CK73FB1E104K CHIP C 0.10UF K
C36 CK73FB1C105K CHIP C 1.0UF K
C37 CK73FB1H102K CHIP C 1000PF K
C38 CK73FB1E104K CHIP C 0.10UF K
C39 CK73FB1H102K CHIP C 1000PF K
C40 CK73FB1C105K CHIP C 1.0UF K
C41,42 CK73FB1E104K CHIP C 0.10UF K
C43 CK73FB1H103K CHIP C 0.010UF K
C44 CK73FB1C105K CHIP C 1.0UF K
C45 CK73FB1H103K CHIP C 0.010UF K
C46 C93-0568-05 CHIP C 47PF J
C47 CM73F2H271J CHIP C 270PF J
C48 CM73F2H391J CHIP C 390PF J
C49-56 C93-0608-05 CHIP C 2700PF K
C57,58 C93-0572-05 CHIP C 100PF J
C59,60 C93-0568-05 CHIP C 47PF J
C61 CM73F2H331J CHIP C 330PF J
C63 C93-0555-05 CHIP C 5.0PF C
C67 C93-0555-05 CHIP C 5.0PF C
C68 CK73FB1E104K CHIP C 0.10UF K
C69 CK73FB1H102K CHIP C 1000PF K
C70 CE04EW1E100M ELECTRO 10UF 25WV
C71 CK73FB1H103K CHIP C 0.010UF K
C72 CK73FB1E104K CHIP C 0.10UF K
C73 CK73FB1H102K CHIP C 1000PF K
C74 CK73FB1E104K CHIP C 0.10UF K
C79 C90-4089-05 ELECTRO 220UF 25WV
C101 C93-0567-05 CHIP C 39PF J
C102 C93-0560-05 CHIP C 10PF D
C104 C93-0572-05 CHIP C 100PF J
C106 C93-0572-05 CHIP C 100PF J
C107 CM73F2H271J CHIP C 270PF J
C108 CM73F2H221J CHIP C 220PF J
C110 CM73F2H271J CHIP C 270PF J
C111 CM73F2H221J CHIP C 220PF J
C117,118 CM73F2H151J CHIP C 150PF J
C125 CK73EF1V225Z CHIP C 2.2UF Z
C127 CK73FB1H102K CHIP C 1000PF K
C130,131 CM73F2H151J CHIP C 150PF J
C132 CC73FSL1H471J CHIP C 470PF J
C133 CK73FB1H103K CHIP C 0.010UF K
C135 CK73FB1E104K CHIP C 0.10UF K
C138 CK73FB1H102K CHIP C 1000PF K
C139,140 CC73FSL1H331J CHIP C 330PF J
C141 CK73FB1H102K CHIP C 1000PF K
C142 CK73FB1E104K CHIP C 0.10UF K
C143 CK73FB1H471K CHIP C 470PF K
C144 CE04EW1E100M ELECTRO 10UF 25WV
C145 CK73FB1H471K CHIP C 470PF K
C146 CK73FB1E104K CHIP C 0.10UF K
C147 CK73FB1H102K CHIP C 1000PF K
C148 CC73FSL1H471J CHIP C 470PF J
C149 CK73FB1H103K CHIP C 0.010UF K
C150 CM73F2H680J CHIP C 68PF J
C151,152 C93-0554-05 CHIP C 4.0PF C
C153 CM73F2H680J CHIP C 68PF J
C154,155 C93-0554-05 CHIP C 4.0PF C
C157 CM73F2H200J CHIP C 20PF J
C158,159 C93-0603-05 CHIP C 1000PF K
C160 C93-0560-05 CHIP C 10PF D
C161,162 CC73FCH1H100D CHIP C 10PF D
C201,202 CK73FB1H102K CHIP C 1000PF K
C203,204 CK73FB1H103K CHIP C 0.010UF K
C205 C91-2691-05 CERAMIC 470PF 250WV
C206 CK73FB1H103K CHIP C 0.010UF K
C207 CE04EW1E471M ELECTRO 470UF 25WV
C208 CK73FB1H103K CHIP C 0.010UF K
C209 CK73FB1E104K CHIP C 0.10UF K
C210 CK73FB1H103K CHIP C 0.010UF K
C211 CK73FB1E104K CHIP C 0.10UF K
C212 CK73FB1H103K CHIP C 0.010UF K
C213 CE04EW1E471M ELECTRO 470UF 25WV
C214 CK73FB1H103K CHIP C 0.010UF K
FINAL UNIT (X45-360X-XX) 0-11 : K,KB,KX 2-71 : E,EB,E2,E2B,EX

Kenwood TS-2000 Specifications

General

Antenna Impedance	50 ohms
Supply Voltage	13.8V DC ±15%
Current Drain TX	20.5A
Receiver Type	Triple Conversion Superheterodyne
Modes	SSB, CW, AM, FM, FSK
Type	Base Station
Frequency Range TX	0.1-60 MHz (HF), 144-148 MHz (VHF), 430-450 MHz (UHF)
Image Rejection	More than 70 dB
Selectivity	2.4 kHz (SSB), 500 Hz (CW), 15 kHz (FM)
Antenna Connector	SO-239
Frequency Range	HF/6m/2m/70cm
