Kenwood TS-2000 Service Manual Supplement

TS-2000/X,TS-B2000
PARTS LIST
9
K : TS-2000 (K) KB : TS-B2000 (K) KX : TS-2000X (K) E : TS-2000 (E)
EB : TS-B2000 (E) E2 : TS-2000 (E2) E2B : TS-B2000 (E2) EX : TS-2000X (E)
Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description
New Desti-
parts nation
New Desti-
parts nation
FINAL UNIT (X45-360X-XX)
L917 L34-1239-05 AIR-CORE COIL
L918,919 L34-1185-05 AIR-CORE COIL
L921,922 L34-1185-05 AIR-CORE COIL
L923 L34-4617-15 AIR-CORE COIL
L924 L34-1239-05 AIR-CORE COIL
L926 L40-2275-34 SMALL FIXED INDUCTOR (22NH)
L927-931 L40-1085-34 SMALL FIXED INDUCTOR (100NH)
L932 L34-4617-15 AIR-CORE COIL
CN803,804 R92-1061-05 JUMPER REST 0 OHM
R1,2 RK73FB2A101J CHIP R 100 J 1/10W
R3 RK73FB2A150J CHIP R 15 J 1/10W
R4 RK73FB2A681J CHIP R 680 J 1/10W
R5 RK73FB2A332J CHIP R 3.3K J 1/10W
R6 RK73FB2A681J CHIP R 680 J 1/10W
R7 RK73FB2A152J CHIP R 1.5K J 1/10W
R8 RK73FB2A471J CHIP R 470 J 1/10W
R9 RK73FB2A100J CHIP R 10 J 1/10W
R10 R92-0670-05 CHIP R 0 OHM
R11 RK73FB2A221J CHIP R 220 J 1/10W
R12 RK73FB2A391J CHIP R 390 J 1/10W
R13 RK73FB2A471J CHIP R 470 J 1/10W
R14 R92-2021-05 CHIP R 2.2 J 1/2W
R15 RK73EB2B221J CHIP R 220 J 1/8W
R16-19 RK73FB2A1R0J CHIP R 1.0 J 1/10W
R20,21 RK73FB2A101J CHIP R 100 J 1/10W
R24 R92-1213-05 CHIP R 100 J 1/2W
R25 RK73FB2A820J CHIP R 82 J 1/10W
R26 RK73FB2A270J CHIP R 27 J 1/10W
R27 R92-2018-05 CHIP R 560 J 1/2W
R30 R92-1318-05 CHIP R 100 J 1W
R31,32 R92-2673-05 RESISTOR 1.0
R33,34 R92-3511-05 RESISTOR 8.2
R35-40 RK73EB2E1R0J CHIP R 1.0 J 1/4W
R41,42 R92-1240-05 CHIP R 10 J 1/4W
R43 RK73FB2A331J CHIP R 330 J 1/10W
R44 RS14DB3A4R7J
FL-PROOF RS 4.7 J 1W
R45,46 RS14DB3D390J
FL-PROOF RS 39 J 2W
R101 R92-1318-05 CHIP R 100 J 1W
R102 RS14DB3A100J
FL-PROOF RS 10 J 1W
R103 RS14DB3F101J
FL-PROOF RS 100 J 3W
R106 R92-1213-05 CHIP R 100 J 1/2W
R107 R92-1212-05 CHIP R 27 J 1/2W
R108 RK73FB2A100J CHIP R 10 J 1/10W
R109 RK73FB2A331J CHIP R 330 J 1/10W
R110 RK73FB2A561J CHIP R 560 J 1/10W
R111 R92-2559-05 RESISTOR 12
R201 RK73FB2A472J CHIP R 4.7K J 1/10W
R202 R92-2536-05 CHIP R 2.2 J 1/4W
R203 RK73FB2A472J CHIP R 4.7K J 1/10W
R204 R92-1259-05 CHIP R 18 J 1/2W
R205 RK73FB2A102J CHIP R 1.0K J 1/10W
R206 RK73FB2A100J CHIP R 10 J 1/10W K,KB,KX
R207 RK73FB2A333J CHIP R 33K J 1/10W
R208 RK73FB2A102J CHIP R 1.0K J 1/10W
R209-212 RK73FB2A101J CHIP R 100 J 1/10W
R213 R92-2021-05 CHIP R 2.2 J 1/2W
R214 R92-0679-05 CHIP R 0 OHM
R216,217 R92-0670-05 CHIP R 0 OHM
R218 RK73FB2A101J CHIP R 100 J 1/10W
R219 RK73FB2A681J CHIP R 680 J 1/10W
R220 RK73FB2A100J CHIP R 10 J 1/10W
R221 RK73FB2A4R7J CHIP R 4.7 J 1/10W
R222 R92-0679-05 CHIP R 0 OHM
R223 RK73FB2A181J CHIP R 180 J 1/10W
R224 RK73FB2A680J CHIP R 68 J 1/10W
R225 RK73FB2A332J CHIP R 3.3K J 1/10W
R226 RK73FB2A103J CHIP R 10K J 1/10W
R227 RK73FB2A122J CHIP R 1.2K J 1/10W
R228 RK73FB2A270J CHIP R 27 J 1/10W
R501,502 RS14DB3F820J
FL-PROOF RS 82 J 3W
R901 RK73FB2A563J CHIP R 56K J 1/10W
R902 R92-0670-05 CHIP R 0 OHM
R903 RK73FB2A470J CHIP R 47 J 1/10W
R904 RK73FB2A274J CHIP R 270K J 1/10W
R906 R92-0670-05 CHIP R 0 OHM
R907 RK73FB2A332J CHIP R 3.3K J 1/10W
R908 R92-0670-05 CHIP R 0 OHM
R909 RK73FB2A470J CHIP R 47 J 1/10W
R910 RK73FB2A183J CHIP R 18K J 1/10W
R911 RK73FB2A221J CHIP R 220 J 1/10W
R912 R92-1221-05 CHIP R 82 J 1/4W
R913 RK73FB2A391J CHIP R 390 J 1/10W
R914 R92-1261-05 CHIP R 150 J 1/2W
R915 R92-1253-05 CHIP R 82 J 1/2W
R916,917 RK73FB2A681J CHIP R 680 J 1/10W
R918 R92-1253-05 CHIP R 82 J 1/2W
R919-922 RK73FB2A183J CHIP R 18K J 1/10W
R923,924 RK73FB2A220J CHIP R 22 J 1/10W
R925 RK73FB2A390J CHIP R 39 J 1/10W
R928 R92-0679-05 CHIP R 0 OHM
VR1 R12-6730-05 TRIMMING POT. (220)
VR2 R12-6737-05 TRIMMING POT. (3.3K)
VR102 R12-6737-05 TRIMMING POT. (3.3K)
VR901 R12-6730-05 TRIMMING POT. (220)
VR902 R12-6737-05 TRIMMING POT. (3.3K)
K1 S76-0424-05 RELAY
K201 S76-0429-05 RELAY
K801,802 S76-0419-05 RELAY
K803 S76-0415-05 RELAY
K804,805 S76-0419-05 RELAY
K806 S76-0415-05 RELAY
K807,808 S76-0419-05 RELAY
K809 S76-0415-05 RELAY
K810,811 S76-0419-05 RELAY
K812 S76-0415-05 RELAY
K813,814 S76-0419-05 RELAY
K815 S76-0415-05 RELAY
K816,817 S76-0419-05 RELAY
K818 S76-0415-05 RELAY
K819,820 S76-0419-05 RELAY
K821 S76-0415-05 RELAY
K822,823 S76-0419-05 RELAY
K824 S76-0415-05 RELAY
D1 DAN235E DIODE
D2 MA2C029W-B VARISTOR
D3 1SS355 DIODE
D5 DAN202K DIODE
D6 1SS355 DIODE

Kenwood TS-2000 Specifications

General

Antenna Impedance	50 ohms
Supply Voltage	13.8V DC ±15%
Current Drain TX	20.5A
Receiver Type	Triple Conversion Superheterodyne
Modes	SSB, CW, AM, FM, FSK
Type	Base Station
Frequency Range TX	0.1-60 MHz (HF), 144-148 MHz (VHF), 430-450 MHz (UHF)
Image Rejection	More than 70 dB
Selectivity	2.4 kHz (SSB), 500 Hz (CW), 15 kHz (FM)
Antenna Connector	SO-239
Frequency Range	HF/6m/2m/70cm
