KERN CXB 3K0.2 User Manual

CXB/CXP-BA-e-1016
43
14 Data output
(CXP models only)
The balance is typically equipped with a RS 232C interface.
14.1 RS 232C interface
The RS 232C interface allows a bi-directional data exchange from the balance to ex-
ternal devices. This data exchange is asynchronous using ASCII - Code.
Pin allocation of balance output plug:
RxD
TxD
SG
2
3
4
5
7
Technical specifications of interface:
Baud rate
9600; 4800; 2400;1200
Start bit
0
Stop bit
2, 1
Parity
nOnE, odd, even
DATA
8,7
FLOW
nOnE
Default settings in bold print.
