KERN CXB-SH-e-0913 - 9 Linearity Calibration

9 Linearity calibration
♦ Before calibrating, please adjust the mini jumper SWA1 to “ADJ” position.
♦ After finish the calibration, please re-adjust the mini jumper SWA1 to
“LOCK” position.
~ Divide the capacity into 5 sections before linearity calibration.
E.g. CXB 30K2 (capacity = 30kg)
Divide it into 5 phases: 3kg, 6kg, 12kg, 12kg, 3kg
(The total calibrated weight should be between 1.1~1.25 times of the capacity
weight. E.g.: 3kg + 6kg + 12kg + 12kg + 3kg = 36kg are 1.2 times of 30kg)
n Turn on the machine, after the scale resets back to zero,
then press key + 1 key + 6 key (at the same time) to enter the linearity
calibration mode. (Please press 9 key to pass over this linearity calibration
mode.)
Weight Piece Weight Pcs
0 0 L. XXXXXX
key in *n value core value
display the number of times of calibration (zero internal value)
♦ *n = the calibrated value of phase X / the calibrated value of 1
st
phase
[*n = multiplier (2,3,4…) of 1
st
calibration weight / 1
st
phase]
♦ *n ⇒ must be an integral
o Press . key
Weight Piece Weight Pcs
0 1 1 XXXXXX
internal value of the phase
