KERN DE - Page 48

DE-BA-e-1052
10
KERN
DE150K20DXL DE300K5DL DE300K50D DE300K50DL
Readability (d) 20 g / 50 g 5 g / 10 g 50 g / 100 g
Weighing range (max) 60 kg / 150 kg 150 kg / 300 kg
Minimum piece weight 40 g 10 g 100 g 200 g
Reproducibility 20 g / 50 g 5 g / 10 g 50 g / 100 g
Linearity ± 40 g / 100 g ± 20 g / 40 g
± 100 g / 200 g
Warm-up time 10 minutes 2 hours 10 minutes
Reference unit weights at
piece count
5, 10, 20, 25, 50
Weighing Units
Details „Weighing units“ chapter 7.9
Recommended
adjustment weight, not
added (class)
Details for „Selection of
the Adjustment weight“
in chapter 8.4
150 kg
( M1 )
300 kg
( F2 )
300 kg
( M1 )
Stabilization time (typical) 2,5 sec.
Electric Supply
DC 15V/600 mA
Operating temperature + 5° C .... + 35° C
Humidity of air max. 80 % (not condensing)
Terminal (B x D x H) mm 226 x 111 x 58
Platform (B x D x H ) mm
650 x 500 x 105 522 x 406 x
100
522 x 403 x 90 650 x 500 x 105
Weight kg (net) 28 16 16 28
