CB/FCB-BA-e-0640
25
8.5 Interface RS232C
Data output via interface RS 232 C
General Information
The previous condition for the data transfer between balance and a peripheral device
(e.g. printer, PC ...) is that the appliances are set to the same interface parameters
(e.g. baud rate, transfer mode ...).
8.5.1 Data transfer mode
Setting of data transfer mode Balance display
1. Keep the key pressed until „Unit" is displayed.
Unit
2. Press key, „Pr“ appears.
Pr
3. To change the setting, press the key.
Pr PC
4. The mode can be converted using the key
(Pr PC; AU PC; AU Pr ; re Cr ; BA Pr ;details chapter 9.4).
AU Pr
5. The changed setting is taken over by pressing
the key.
6. The balance returns to the weighing mode. 0.0 g
8.5.2 Baud rate
The baud rate necessary for the measuring values transfer can be set.
In the following example the baud rate is set to 9600 baud.
Setting of baud rate Balance display
1. Keep the key pressed until „Unit" is displayed.
Unit
2. Press key
Pr
3. Press key, „baud“ appears.
Baud
4. Confirm by pressing the key
4800
5. The baud rate can be changed using the key (1200,
2400, 4800, 9600, 19200).
9600
6. The changed setting is taken over by pressing
the key.
7. The balance returns to the weighing mode. 0.0 g
