Interface description
User manual ME-Nr. 22017071 01/07
Status word A
Status Bit
FunctionSelection6543210
Decimal
position
X00 0 1 0 0 0
X0 0 0 1
X 0 1 0
0.X 0 1 1
0.0X 1 0 0
0.00X 1 0 1
0.000X 1 1 0
0.0000X 1 1 1
Numerical
increment
X1 0 1
X2 1 0
X5 1 1
Status word B Status word C
Function / value Bit Function / value Bit
Gross / net: Net = 1 0 0 0
Sign: Negative = 1 1 0 1
Overload = 1 2 0 2
Movement = 1 3 Print request = 1 3
lb/kg: kg = 1 4 Extended = 1 4
1515
Powerup = 1 6 Manual taring, only kg = 1 6
